ASP Interface

This chapter describes functions used by an Active Server Page (ASP) interface with examples.

1. Overview

An ASP interface is a script that enables to dynamically develop web pages for users in a web environment. To call a Tmax service in ASP, the tmaxcomcli.dll interface provided by Tmax must be used.

tmaxcomcli.dll operates as an inprocess server with the following 4 interface modules.

Module Description

Tmaxcom.Atmi

Includes methods that wrap basic Tmax functions.

Tmaxcom.Etc

Includes methods that wrap functions that are not provided by Tmaxcom.Atmi.

Tmaxcom.Fdl

Includes methods that wrap functions for handling Tmax field buffers.

Tmaxcom.Tx

Includes methods that wrap Tmax transaction functions.

A Tmax service can be used in ASP by creating an object for an interface above and then calling a corresponding method. For more information, refer to Example Program.

The following describes each method that can be used by an ASP interface.

  • Atmi interface methods

    Method Description

    OnGettperrno

    Returns an error value set when a Tmax system is called.

    OnGettpurcode

    Returns urcode set when a service calls tpreturn()

    OnTpacall

    Sends an asynchronous service request.

    OnTpalloc

    Allocates a typed buffer.

    OnTpcall

    Sends a synchronous service request and receives its reply.

    OnTpcancel

    Cancels a reply with a call descriptor returned by OnTpacall().

    OnTpconnect

    Establishes a connection to an interactive service.

    OnTpdiscon

    Ends a connection to an interactive service.

    OnTpend

    Ends a connection to a Tmax system.

    OnTpfree

    Frees memory allocated for a typed buffer.

    OnTpget

    Gets a value to which a pointer to a buffer allocated by OnTpalloc() points.

    OnTpgetrply

    Receives a reply to an asynchronous request of a service.

    OnTpput

    Sets a value in the location to which a pointer to a buffer allocated by OnTpalloc() points.

    OnTprealloc

    Reallocates a typed buffer.

    OnTprecv

    Receives data sent from a connected program in interactive communication.

    OnTpsend

    Sends a message in interactive communication.

    OnTpstart

    Connects to a Tmax system.

    OnTptypes

    Provides information about buffer type and subtype.

  • Non-Atmi interface methods

    Method Description

    OnTmax_chk_conn

    Checks whether a client is connected to a Tmax system.

    OnTmaxreadenv

    Loads environment variables from a file.

    OnTp_sleep

    Sleeps for up to sec and returns immediately when data arrives.

    OnTp_usleep

    Sleeps for up to usec time and returns immediately when data arrives.

    OnTpdeq

    Reads a result of a service request through tpenq() or data that a service name was specified as NULL when tpenq() was used.

    OnTpenq

    Saves data in an RQ.

    OnTperrordetail

    Gets detailed information about an error that occurred when a Tmax system is called.

    OnTpextsvcinfo

    Gets detailed information about data that was read from an RQ through OnTpdeq().

    OnTpextsvcname

    Gets the name of a service that was used for data that was read from an RQ through OnTpdeq().

    OnTpgetenv

    Returns a value in a registered environment variable.

    OnTpputenv

    Sets a specified value in a specified environment variable.

    OnTpqstat

    Returns statistics about data in a current queue.

    OnTpqsvcstat

    Returns statistics about data for a specified service in a current queue.

    OnTpreissue

    Puts service request data that is in a fail queue into a request queue

    OnTpreset

    Immediately ends a connection to a client.

    OnTpset_timeout

    Changes blocking timeout (service timeout) that is set in a server.

    OnTpsubqname

    Returns the name of a subqueue that corresponds to a specified subqueue number.

    OnTptobackup

    Allows a client to connect to a Tmax backup system.

  • FDL interface method

    Method Description

    OnFballoc

    Calculates the size of a field buffer and then allocates memory.

    OnFbcalcsize

    Calculates a field buffer size to allocate the field buffer in memory with OnTpalloc().

    OnFbdelall

    Deletes all data in a field with a specified key from a field buffer.

    OnFbdelete

    Deletes data of a specified order number in a field with a specified key from a field buffer.

    OnFbfldcount

    Calculates and returns the number of fields in a field buffer.

    OnFbfree

    Frees memory allocated to a field buffer.

    OnFbget

    Gets field data that corresponds to a specified field key from a field buffer.

    OnFbget_fbsize

    Gets and returns a field buffer size.

    OnFbget_fldkey

    Gets and returns a field key that corresponds to a specified field name.

    OnFbget_fldname

    Gets and returns a field name that corresponds to a specified field key.

    OnFbget_fldtype

    Gets and returns the type of a specified field key as an integer.

    OnFbget_strfldtype

    Gets and returns the type of a specified field key as a string.

    OnFbget_unused

    Calculates and returns the size of an unused field buffer allocated in memory.

    OnFbget_used

    Calculates and returns the size of a currently used field buffer allocated in memory.

    OnFbgetc

    Converts field data in a field buffer to a specified type and sequentially returns the converted data.

    OnFbgetf

    Sequentially returns field data in a field buffer.

    OnFbgetnth

    Gets and returns the number of fields that contain specified data with a specified field key.

    OnFbgetntht

    Gets and returns an order number of a field that contains specified data with a specified field key.

    OnFbgetval

    Gets field data with a specified field key and order number from a field buffer and returns the data.

    OnFbgetvali

    Converts field data with a specified field key and order number to an integer and returns the converted data.

    OnFbgetvals

    Converts field data with a specified field key and order number to a string and returns the converted data.

    OnFbgetvalt

    Converts field data with a specified field key and order number to a specified type and returns the converted data.

    OnFbinit

    Initializes a field buffer.

    OnFbinsert

    Inserts data to a field with a specified field key and order number in a field buffer.

    OnFbisfbuf

    Checks whether a specified field buffer is valid (whether a variable is a buffer allocated by OnFballoc() or OnTpalloc()).

    OnFbispres

    Checks whether field data with a specified field key and order number exists.

    OnFbkeynm_unload

    Deletes existing data loaded in memory and loads a file set in the FDLFILE environment variable.

    OnFbkeyoccur

    Returns the number of fields with a specified field key in a field buffer.

    OnFbmake_fldkey

    Dynamically creates a field key.

    OnFbnmkey_unload

    Deletes existing data loaded in memory and loads a file set in the FDLFILE environment variable.

    OnFbput

    Add a field to a field buffer.

    OnFbputt

    Converts data to a specified type, adds a filed to a field buffer, and then saves the data in the field.

    OnFbrealloc

    Reallocates memory to a field buffer.

    OnFbstrerror

    Returns a field buffer error as a string.

    OnFbtypecvt

    Converts field data to a specified type and returns the converted data.

    OnFbupdate

    Converts data with a specified field key and order number in a field buffer.

    OnGetfberrno

    Returns an error value when an error occurs while a field buffer related API function is executed.

    OnGetfberror

    Returns an error value when an error occurs while a field buffer related API function is executed.

  • Tx interface method

    Method Description

    OnTx_begin

    Starts a global transaction.

    OnTx_commit

    Commits a global transaction.

    OnTx_rollback

    Rolls back a global transaction.

    OnTx_set_transaction_timeout

    Configures timeout for a global transaction.

For information about functions that are internally called by methods above, refer to Tmax FDL Reference Guide or Tmax Reference Guide.

2. Atmi Interface Methods

2.1. OnGettperrno

Returns an error value set when a Tmax system is called.

  • Prototype

    OnGettperrno()

  • Return value

    Returns an error value.

  • Related functions

    OnTpurcode(), OnTpstrerror()

2.2. OnGettpurcode

Returns urcode set when a service calls tpreturn().

  • Prototype

    OnGettpurcode()

  • Return value

    Returns urcode.

  • Related functions

    OnGettperrno(), OnTpstrerror()

2.3. OnTpacall

Sends an asynchronous service request by calling tpacall().

  • Prototype

    OnTpacall(VARIANT svc, VARIANT data, VARIANT len, VARIANT flags)

  • Parameter

    Parameter Description

    svc

    Name of a service to be requested.

    data

    Pointer to a data part of a request. If the data is not NULL, the pointer must be a pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    len

    Length of data to be sent.

    flags

    flags used to call tpacall().

  • Return value

    Return value Description

    Descriptor

    Function call succeeded. This descriptor is used as a parameter of a method such as OnTpgetrply() and OnTpcancel().

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpcall(), OnTpgetrply(), OnGettperrno()

2.4. OnTpalloc

Allocates a typed buffer by calling tpalloc().

  • Prototype

    OnTpalloc(VARIANT type, VARIANT subtype, VARIANT size)

  • Parameter

    Parameter Description

    type

    Buffer type (e.g., FIELD, STRING).

    subtype

    Used if a structure buffer is used. This parameter is not used in ASP.

    size

    Buffer size.

  • Return value

    Return value Description

    Pointer to a valid typed buffer

    Function call succeeded.

    NULL

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTprealloc(), OnTpfree(), OnGettperrno()

2.5. OnTpcall

Sends a synchronous service request and receives its reply by calling tpcall().

  • Prototype

    OnTpcall(VARIANT svc, VARIANT idata, VARIANT ilen, VARIANT *odata,
         VARIANT *olen, VARIANT flags)

  • Parameter

    Parameter Description

    svc

    Name of a service to be requested.

    idata

    Pointer to a data part of a request. If the data is not NULL, the pointer must be a pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    ilen

    Length of data to be sent.

    odata

    Pointer to a reply receive buffer allocated by OnTpalloc() or OnFballoc().

    olen

    Length of data received.

    flags

    flags used to tpcall().

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpalloc(), OnTpacall(), OnTpgetrply(), OnGettperrno()

2.6. OnTpcancel

Cancels a reply with a call descriptor (cd) returned by OnTpacall(), by calling tpcancel().

  • Prototype

    OnTpcancel(VARIANT cd)

  • Parameter

    Parameter Description

    cd

    Descriptor returned by OnTpacall().

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpacall(), OnTpgetrply(), OnGettperrno()

2.7. OnTpconnect

Establishes a connection to an interactive service by calling tpconnect().

  • Prototype

    OnTpconnect(VARIANT svc, VARIANT data, VARIANT len, VARIANT flags)

  • Parameter

    Parameter Description

    svc

    Name of a service to be connected.

    data

    Pointer to data to be sent to a service routine during connection configuration.

    len

    Size of data to be sent to a service routine during connection configuration.

    flags

    Flags used for communication connections.

    • TPNOTRAN

    • TPSENDONLY

    • TPRECVONLY

    • TPNOTIME

    • TPSIGRSTRT

    Either TPSENDONLY or TPRECVONLY must be set for OnTpconnect().

  • Return value

    Return value Description

    Descriptor

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTprecv(), OnTpsend(), OnTpdiscon(), OnGettperrno()

2.8. OnTpdiscon

Ends a connection to an interactive service by calling tpdiscon().

  • Prototype

    OnTpdiscon(VARIANT cd)

  • Parameter

    Parameter Description

    cd

    Descriptor returned by OnTpconnect().

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpconnect(), OnTprecv(), OnTpsend(), OnGettperrno()

2.9. OnTpend

Ends a connection to a Tmax system by calling tpend().

  • Prototype

    OnTpend()

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpstart(), OnGettperrno()

2.10. OnTpfree

Frees memory allocated for a typed buffer by calling tpfree().

  • Prototype

    OnTpfree(VARIANT ptr)

  • Parameter

    Parameter Description

    ptr

    Pointer to a buffer to which memory to be freed was allocated.

  • Return value

    None.

  • Related functions

    OnTpalloc()

2.11. OnTpget

Gets a value to which a pointer to a buffer allocated by OnTpalloc() points.

  • Prototype

    OnTpget(VARIANT buf, VARIANT *loc)

  • Parameter

    Parameter Description

    buf

    Pointer to a buffer allocated by OnTpalloc().

    value

    Variable used to receive a value.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed.

  • Example

    Dim buf
Dim rVal
Dim msg
Dim i
...
buf = OnTpalloc ("STRING", "", CINT(0))
...
OnTpput buf, "abcd"
rVal = OnTpcall("TOUPPER", buf, CINT(0), buf2, i, CINT(0))
...
OnTpget buf, msg
...

  • Related functions

    OnTpput()

2.12. OnTpgetrply

Receives a reply to an asynchronous request of a service by calling tpgetrply().

  • Prototype

    OnTpgetrply(VARIANT cd, VARIANT *data, VARIANT *len, VARIANT flags)

  • Parameter

    Parameter Description

    cd

    Descriptor returned by OnTpacal().

    data

    Pointer to a reply receive buffer allocated by OnTpalloc() or OnFballoc().

    len

    Length of data received.

    flags

    flags used to call tpcall().

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpalloc(), OnTpacall(), OnGettperrno()

2.13. OnTpput

Sets a value in the location to which a pointer to a buffer allocated by OnTpalloc() points.

  • Prototype

    OnTpput(VARIANT *buf, VARIANT value)

  • Parameter

    Parameter Description

    buf

    Pointer to a buffer allocated by OnTpalloc().

    value

    Value to be set in buf.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed.

  • Example

    Dim buf
Dim rVal
Dim msg
Dim i
...
buf = OnTpalloc ("STRING", "", CINT(0))
...
OnTpput buf, "abcd"
rVal = OnTpcall("TOUPPER", buf, CINT(0), buf2, i, CINT(0))
...
OnTpget buf, msg
...

  • Related functions

    OnTpget()

2.14. OnTprealloc

Reallocates a typed buffer by calling tprealloc().

  • Prototype

    OnTprealloc(VARIANT ptr, VARIANT size)

  • Parameter

    Parameter Description

    ptr

    Pointer to a typed buffer to be reallocated.

    size

    Size of a typed buffer to be reallocated.

  • Return value

    Return value Description

    Pointer to a valid typed buffer

    Function call succeeded.

    NULL

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpalloc(), OnTpfree(), OnGettperrno()

2.15. OnTprecv

Receives data sent from a connected program in interactive communication by calling tprecv().

  • Prototype

    OnTprecv(VARIANT cd, VARIANT *data, VARIANT *len, VARIANT flags, VARIANT *revent)

  • Parameter

    Parameter Description

    cd

    Descriptor returned by OnTpconnect().

    data

    Data receive buffer allocated by OnTpalloc() or OnFballoc().

    len

    Variable used to receive the data length.

    flags

    Flags that can be set in communication with an interactive service.

    The following flags values are available:

    • TPNOCHANGE

    • TPNOBLOCK

    • TPNOTIME

    • TPSIGRSTRT

    revent

    If an event for the cd parameter exists, OnTpsend() will fail and data will not be sent. The event type is returned and saved in revent.

    The following events are available:

    • TPEV_DISCONIMM

    • TPEV_SVCERR

    • TPEV_SVCFAIL

    For more information, refer to Tmax Reference Guide.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. If revent is TREV_SVCFAIL, urcode sent when tpreturn() is called is set and used by OnGettpurcode().

  • Related functions

    OnTpconnect(), OnTpsend(), OnTpdiscon(), OnGettperrno()

2.16. OnTpsend

Sends a message in interactive communication by calling tpsend(). A function caller must have a communication control.

  • Prototype

    OnTpsend(VARIANT cd, VARIANT data, VARIANT len, VARIANT flags, VARIANT *revent)

  • Parameter

    Parameter Description

    cd

    Descriptor returned by OnTpconnect().

    data

    Buffer allocated by OnTpalloc() or OnFballoc().

    len

    Data length.

    flags

    Flags that can be set in communication with an interactive service.

    The following flags values are available:

    • TPNOBLOCK

    • TPNOTIME

    • TPRECVONLY

    • TPSIGRSTRT

    revent

    If an event for the cd parameter exists, OnTpsend() will fail and data will not be sent. The event type is returned and saved in revent.

    The following events are available:

    • TPEV_DISCONIMM

    • TPEV_SVCERR

    • TPEV_SVCFAIL

    For more information, refer to Tmax Reference Guide.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. If revent is TREV_SVCFAIL, urcode sent when tpreturn() is called is set and used by OnGettpurcode().

  • Related functions

    OnTpconnect(), OnTprecv(), OnTpdiscon(), OnGettperrno()

2.17. OnTpstart

Connects to a Tmax system by calling tpstart(). This function receives a member to be used as a parameter of TPSTART_T through a parameter.

  • Prototype

    OnTpstart(VARIANT usrname, VARIANT cltname, VARIANT dompwd, VARIANT usrpwd,
          VARIANT flags)

  • Parameter

    Parameter Description

    usrname

    Client name.

    cltname

    Account used for user authentication security

    dompwd

    Password used for system access security.

    usrpwd

    Password used for user authentication security.

    flags

    Determines an unrequested message type and system access method.

  • Return value

    Return value Description

    0 (main)

    1 (backup)

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpend(), OnTmaxreadenv(), OnGettperrno()

2.18. OnTptypes

Provides information about buffer type and subtype by calling tptypes().

  • Prototype

    OnTptypes(VARIANT ptr, VARIANT *type, VARIANT *subtype)

  • Parameter

    Parameter Description

    ptr

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    type

    Type of a pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    subtype

    Subtype of a pointer to a buffer allocated by OnTpalloc() or OnFballoc().

  • Return value

    Return value Description

    Buffer size

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpsubtypes(), OnGettperrno()

3. Non-Atmi Interface Methods

3.1. OnTmax_chk_conn

Checks whether a client is connected to a Tmax system by calling tptobackup().

  • Prototype

    OnTmax_chk_conn(VARIANT timeout)

  • Parameter

    Parameter Description

    timeout

    Blocking timeout.

  • Return value

    Return value Description

    0

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

3.2. OnTmaxreadenv

Loads environment variables from a file by calling tmaxreadenv().

  • Prototype

    OnTmaxreadenv(VARIANT file, VARIANT label)

  • Parameter

    Parameter Description

    file

    Name of a file that includes environment information of a system to be connected.

    label

    Delimiter for environment information registered in a file.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed.

  • Related functions

    OnTpstart()

3.3. OnTp_sleep

Sleeps until data arrives and immediately returns the data when the data arrives by calling tp_sleep(). This function sleeps for a specified time and then returns if the time is reached.

  • Prototype

    OnTp_sleep(VARIANT sec)

  • Parameter

    Parameter Description

    sec

    Maximum time to wait for data. (Unit: seconds)

  • Return value

    Return value Description

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

    0

    Data did not arrive for a time specified in sec.

    Positive integer

    Data arrived.

  • Related functions

    OnTp_usleep()

3.4. OnTp_usleep

Sleeps until data arrives and immediately returns the data when the data arrives by calling tp_usleep(). This function sleeps for a specified time and then returns if the time is reached.

  • Prototype

    OnTp_sleep(VARIANT usec)

  • Parameter

    Parameter Description

    usec

    Maximum time to wait for data. (Unit: milliseconds)

  • Return value

    Return value Description

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

    0

    Data did not arrive for a time specified in usec.

    Positive integer

    Data arrived.

  • Related functions

    OnTp_usleep()

3.5. OnTpdeq

Reads a result of a service request through tpenq() or data that a service name was specified as NULL when tpenq() was used, by calling tpdeq(). If TPNOREPLY is set to flags when tpenq() is used, a service result cannot be received.

  • Prototype

    OnTpdeq(VARIANT qname, VARIANT svc, VARIANT *data, VARIANT *len, VARIANT flags)

  • Parameter

    Parameter Description

    qname

    Name of an RQ in which data was saved.

    svc

    Same name as that used in OnTpenq().

    data

    Buffer allocated by OnTpalloc() or OnFballoc(). A service result will be sent to this buffer.

    len

    Length of data to be received.

    flags

    Same flags values as the values that are available in tpdeq() can be set.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpenq()

3.6. OnTpenq

Saves data in an RQ by calling tpenq().

  • Prototype

    OnTpenq(VARIANT qname, VARIANT svc, VARIANT data, VARIANT len, VARIANT flags)

  • Parameter

    qname Name of an RQ in which data will be saved.

    svc

    Name of a service to be requested. If the name is NULL, data will be saved in an RQ and no service is executed. If the name is not NULL, data will be saved in an RQ and then the service will be executed.

    data

    Pointer to data to be requested through a service. A buffer that contains the data must have been allocated by OnTpalloc() or OnFballoc() unless the value is NULL.

    len

    Length of data to be sent.

    flags

    Same flags values as the values that are available in tpenq() can be set.

  • Return value

    Return value Description

    queue descriptor (qd)

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpdeq()

3.7. OnTperrordetail

Gets detailed information about an error that occurred when a Tmax system is called, by calling tperrordetail().

  • Prototype

    OnTperrordetail(VARIANT i)

  • Parameter

    Parameter Description

    i

    Error value.

  • Return value

    Return value Description

    -1

    An unknown error occurred.

    1

    An application error occurred.

    2

    A system error occurred.

3.8. OnTpextsvcinfo

Gets detailed information about data that was read from an RQ through OnTpdeq(), by calling tpextsvcinfo().

  • Prototype

    OnTpextsvcinfo(VARIANT data, VARIANT *svc, VARIANT *type, VARIANT *errcode)

  • Parameter

    Parameter Description

    data

    Pointer to data that was read through OnTpdeq(). A buffer that contains the data must have been allocated by OnTpalloc() or OnFballoc().

    svc

    Variable in which a service name will be saved.

    type

    One of the following values that show a result of the data.

    • TPREQ(0)

    • TPFAIL(1)

    • TPSUCCESS(2)

    • TPERR(-1)

    errcode

    Error code that will be set if an error occurs.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

3.9. OnTpextsvcname

Gets the name of a service that was used for data that was read from an RQ through OnTpdeq(), by calling tpextsvcname().

  • Prototype

    OnTpextsvcname(VARIANT data, VARIANT *svc)

  • Parameter

    Parameter Description

    data

    Pointer to data that was read through OnTpdeq(). A buffer that contains the data must have been allocated by OnTpalloc() or OnFballoc().

    svc

    Variable in which a service name will be saved.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

3.10. OnTpgetenv

Returns a value in a registered environment variable by calling tpgetenv().

  • Prototype

    OnTpgetenv(VARIANT str)

  • Parameter

    Parameter Description

    str

    Name of a registered environment variable.

  • Return value

    Return value Description

    Pointer to a value in an environment variable

    Function call succeeded.

    NULL

    Function call failed.

  • Related functions

    OnTpputenv()

3.11. OnTpputenv

Sets a specified value in a specified environment variable by calling tpputenv(). If the environment variable already exists, existing value will be replaced. If not, a new value will be added.

  • Prototype

    OnTpputenv(VARIANT str)

  • Parameter

    Parameter Description

    str

    Value to be saved in an environment variable.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed.

  • Related functions

    OnTpgetenv()

3.12. OnTpqstat

Returns statistics about data in a current queue by calling tpqstat().

  • Prototype

    OnTpqstat(VARIANT qname, VARIANT type)

  • Parameter

    Parameter Description

    qname

    Name of an RQ registered in a Tmax configuration file.

    type

    One of the following values can be set.

    • 0: Used to compile statistics about data in fail, request, and reply queues.

    • 1: Used to compile statistics about data in a fail queue.

    • 2: Used to compile statistics about data in a request queue.

    • 3: Used to compile statistics about data in a reply queue.

  • Return value

    Return value Description

    Statistics

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpsvcstat()

3.13. OnTpqsvcstat

Returns statistics about data for a specified service in a current queue by calling tpqsvcstat.

  • Prototype

    OnTpqsvcstat(VARIANT qname, VARIANT svc, VARIANT type)

  • Parameter

    Parameter Description

    qname

    Name of an RQ registered in a Tmax configuration file.

    svc

    Name of a service for which statistics will be compiled. If this name is NULL, a result will be the same as in OnTpqstat().

    type

    One of the following values can be set.

    • 0: Used to compile statistics about data in fail, request, and reply queues.

    • 1: Used to compile statistics about data in a fail queue.

    • 2: Used to compile statistics about data in a request queue.

    • 3: Used to compile statistics about dat in a reply queue.

  • Return value

    Return value Description

    Statistics

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpqstat()

3.14. OnTpreissue

Puts service request data that is in a fail queue into a request queue, by calling tpreissue(). Data can be in a fail queue because a service fails due to a network or server error during the service execution with an RQ by using OnTpdeq().

  • Prototype

    OnTpreissue(VARIANT qname, VARIANT filter, VARIANT flags)

  • Parameter

    Parameter Description

    qname

    Name of RQ registered in a Tmax configuration file.

    filter

    Not supported. NULL is set.

    flags

    Not supported. 0 is set.

  • Return value

    Return value Description

    0 (Normal)

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpenq(), OnTpdeq()

3.15. OnTpreset

Immediately ends a connection to a client by calling tpreset().

  • Prototype

    OnTpreset()

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

3.16. OnTpset_timeout

Changes blocking timeout (service timeout) that is set in a server by calling tpset_timeout().

  • Prototype

    OnTpset_timeout(VARIANT sec)

  • Parameter

    Parameter Description

    sec

    Blocking timeout.

  • Return value

    Return value Description

    0

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

3.17. OnTpsubqname

Returns the name of a subqueue that corresponds to a specified subqueue number by calling tpsubqname().

  • Prototype

    OnTpsubqname(VARIANT type)

  • Parameter

    Parameter Description

    type

    One of the following can be specified as a subqueue number.

    • 0: RQ_ANY (fail, request, reply queues)

    • 1: RQ_FAIL (fail queue)

    • 2: RQ_REQ (request queue)

    • 3: RQ_RPLY (reply queue)

  • Return value

    Return value Description

    Subqueue name

    Function call succeeded.

    NULL

    Function call failed. An error value is obtained by calling OnGettperrno().

3.18. OnTptobackup

Allows a client to connect to a Tmax backup system by calling tptobackup. To use this method, TMAX_BACKUP_ADDR and TMAX_BACKUP_PORT must have been set.

  • Prototype

    OnTptobackup()

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnTpstart()

4. FDL Interface Methods

4.1. OnFballoc

Calculates the size of a field buffer and then allocates memory by calling fballoc().

  • Prototype

    OnFballoc(VARIANT count, VARIANT len)

  • Parameter

    Parameter Description

    count

    Number of fields in which data will be saved.

    len

    Total data size. (Unit: bytes)

  • Return value

    Return value Description

    Pointer to an allocated memory

    Function call succeeded.

    NULL

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbcalcsize(), OnTpalloc()

4.2. OnFbcalcsize

Calculates a field buffer size to allocate the field buffer in memory with OnTpalloc(), by calling fbcalcsize().

  • Prototype

    OnFbcalcsize(VARIANT count, VARIANT datalen)

  • Parameter

    Parameter Description

    count

    Number of fields in which data will be saved.

    datalen

    Data size in a field buffer. (Unit: bytes)

  • Return value

    Field buffer size in bytes.

  • Related functions

    OnFballoc(), OnTpalloc()

4.3. OnFbdelall

Deletes all data in a field with a specified key from a field buffer by calling fbdelall().

  • Prototype

    OnFbdelall(VARIANT fbuf, VARIANT fldkey)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

  • Return value

    Return value Description

    Number of deleted fields

    Function call succeeded.

    -1

    A specified field key cannot be found in a field buffer. An error value is obtained by calling OnGettperrno().

4.4. OnFbdelete

Deletes data of a specified order number in a field with a specified key from a field buffer by calling fbdelete().

  • Prototype

    OnFbdelete(VARIANT fbuf, VARIANT fldkey, VARIANT nth)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    nth

    Order number of a field.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbupdate(), OnFbinsert()

4.5. OnFbfldcount

Calculates and returns the number of fields in a field buffer by calling fbfldcount().

  • Prototype

    OnFbfldcount(VARIANT fbuf)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

  • Return value

    Number of fields in a specified field buffer. If no field exists, 0 will be returned.

4.6. OnFbfree

Frees memory allocated to a field buffer by calling fbfree().

  • Prototype

    OnFbfree(VARIANT fbuf)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGetfberrno().

  • Related functions

    OnFballoc(), OnTpalloc(), OnTpfree()

4.7. OnFbget

Gets field data that corresponds to a specified field key from a field buffer by calling fbget().

  • Prototype

    OnFbget(VARIANT fbuf, VARIANT fldkey, VARIANT *loc, VARIANT *fldlen)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    loc

    Buffer in which field data will be saved. This buffer must have been allocated by OnTpalloc().

    fldlen

    Length of field data to be received.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbput(), OnFbgett()

4.8. OnFbget_fbsize

Gets and returns a field buffer size by calling fbfree().

  • Prototype

    OnFbget_fbsize(VARIANT fbuf)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

  • Return value

    Size of a field buffer allocated in memory.

  • Related functions

    OnFballoc(), OnTpalloc()

4.9. OnFbget_fldkey

Gets and returns a field key that corresponds to a specified field name by calling fbget_fldkey().

  • Prototype

    OnFbget_fldkey(VARIANT name)

  • Parameter

    Parameter Description

    name

    Field name.

  • Return value

    Return value Description

    Field key

    Function call succeeded.

    0

    A specified field name does not exist in a field table.

  • Related functions

    OnFbget_fldname(), OnFbget_fldtype()

4.10. OnFbget_fldname

Gets and returns a field name that corresponds to a specified field key by calling fbget_fldname().

  • Prototype

    OnFbget_fldname(VARIANT fldkey)

  • Parameter

    Parameter Description

    fldkey

    Field key.

  • Return value

    Return value Description

    Field name

    Function call succeeded.

    NULL

    A field name that corresponds to a specified field key does not exist in a field table.

  • Related functions

    OnFbget_fldkey(), OnFbget_fldtype()

4.11. OnFbget_fldtype

Gets and returns the type of a specified field key as an integer by calling fbget_fldtype().

  • Prototype

    OnFbget_fldtype(VARIANT fldkey)

  • Parameter

    Parameter Description

    fldkey

    Field key.

  • Return value

    Return value Field Type

    1

    character

    2

    short integer

    3

    integer

    4

    long integer

    5

    float

    6

    double

    7

    string

    8

    character array (CARRAY)

  • Related functions

    OnFbget_fldkey(), OnFbget_fldname()

4.12. OnFbget_strfldtype

Gets and returns the type of a specified field key as a string by calling fbget_strfldtype().

  • Prototype

    OnFbget_strfdltype(VARIANT fldkey)

  • Parameter

    Parameter Description

    fldkey

    Field key.

  • Return value

    Return value Description

    Empty string

    There is no field type that corresponds to a specified field key, or the specified field key is invalid.

    String

    A field type that corresponds to a specified field key is returned as a string.

  • Related functions

    OnFbget_fldtype()

4.13. OnFbget_unused

Calculates and returns the size of an unused field buffer allocated in memory by calling fbget_unused()

  • Prototype

    OnFbget_unused(VARIANT fbuf)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

  • Return value

    Size of unused memory allocated to a field buffer in bytes.

  • Related functions

    OnFbget_used()

4.14. OnFbget_used

Calculates and returns the size of a currently used field buffer allocated in memory by calling fbget_used().

  • Prototype

    OnFbget_used(VARIANT fbuf)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

  • Return value

    Size of currently used memory allocated to a field buffer in bytes.

  • Related functions

    OnFbget_unused()

4.15. OnFbgetc

Converts field data in a field buffer to a specified type and sequentially returns the converted data, by calling fbgetc().

  • Prototype

    OnFbgetc(VARIANT fbuf, VARIANT fldkey, VARIANT *loc, VARIANT *len, VARIANT *pos,
         VARIANT totype)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    loc

    Buffer in which field data to be received will be saved. This buffer must have been allocated by OnTpalloc().

    fldlen

    Length of field data to be received.

    pos

    Position of next data to be read.

    totype

    One of the following types to which field data can be converted.

    • FB_CARRAY(8)

    • FB_SHORT(2)

    • FB_DOUBLE(6)

    • FB_LONG(4)

    • FB_STRING(7)

    • FB_CHAR(1)

    • FB_FLOAT(5)

    • FB_INT(3)

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    A specified field key does not exist in a field buffer. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbget(), OnFbgetf()

4.16. OnFbgetf

Sequentially returns field data in a field buffer by calling fbgetf().

  • Prototype

    OnFbgetf(VARIANT fbuf, VARIANT fldkey, VARIANT *loc, VARIANT *fldlen,
         VARIANT *pos)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    loc

    Buffer in which field data to be received will be saved. This buffer must have been allocated by OnTpalloc().

    fldlen

    Length of field data to be received.

    pos

    Position of next data to be read.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    A specified field key does not exist in a field buffer. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbget(), OnFbgetc()

4.17. OnFbgetnth

Gets and returns the number of fields that contain specified data with a specified field key, by calling fbgetnth().

  • Prototype

    OnFbgetnth(VARIANT fbuf, VARIANT fldkey, VARIANT value, VARIANT len)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    value

    Data to be searched for.

    len

    Length of data to be searched for.

  • Return value

    Return value Description

    The number of fields

    Function call succeeded.

    -1

    A specified field key does not exist in a field buffer. An error value is obtained by calling OnGettperrno().

4.18. OnFbgetntht

Gets and returns an order number of a field that contains specified data with a specified field key, by calling fbgetntht().

  • Prototype

    OnFbgetntht(VARIANT fbuf, VARIANT fldkey, VARIANT value, VARIANT len,
            VARIANT fromtype)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    value

    Data to be searched for.

    len

    Length of data to be searched for.

    fromtype

    Field type. If a data type set in this fromtype parameter is different from the type of a field with a specified field key set in the fldkey parameter, the type of data set in the value parameter will be converted to the field type.

    One of the following field types can be set.

    • FB_CHAR(1)

    • FB_SHORT(2)

    • FB_INT(3)

    • FB_LONG(4)

    • FB_FLOAT(5)

    • FB_DOUBLE(6)

    • FB_STRING(7)

    • FB_CARRAY(8)

  • Return value

    Return value Description

    Order number of a field

    Function call succeeded.

    -1

    A specified field key does not exist in a field buffer. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbgetntht()

4.19. OnFbgetval

Gets field data with a specified field key and order number from a field buffer and returns the data, by calling fbgetval().

  • Prototype

    OnFbgetval(VARIANT fbuf, VARIANT fldkey, VARIANT nth, VARIANT *len)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    nth

    Order number of a field.

    len

    Length of data to be read.

  • Return value

    Return value Description

    String

    Function call succeeded.

    NULL

    A specified field key or order number does not exist in a field buffer. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbgetvalt(), OnFbgetvals(), OnFbgetvali()

4.20. OnFbgetvali

Converts field data with a specified field key and order number to an integer and returns the converted data, by calling fbgetvali().

  • Prototype

    OnFbgetvali(VARIANT fbuf, VARIANT fldkey, VARIANT nth)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    nth

    Order number of a field.

  • Return value

    Return value Description

    Integer

    Function call succeeded.

    -1

    A specified field key does not exist in a field buffer, or an error occurred during the function execution. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbgetvalt(), OnFbgetvals(), OnFbgetval()

4.21. OnFbgetvals

Converts field data with a specified field key and order number to a string and returns the converted data, by calling fbgetvals().

  • Prototype

    OnFbgetvals(VARIANT fbuf, VARIANT fldkey, VARIANT nth)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    nth

    Order number of a field.

  • Return value

    Return value Description

    String

    Function call succeeded.

    NULL

    A specified field key does not exist in a field buffer, or an error occurred during the function execution. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbgetvalt(), OnFbgetval(), OnFbgetvali()

4.22. OnFbgetvalt

Converts field data with a specified field key and order number to a specified type and returns the converted data, by calling fbgetvalt().

  • Prototype

    OnFbgetvalt(VARIANT fbuf, VARIANT fldkey, VARIANT nth, VARIANT *len,
            VARIANT totype)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    nth

    Order number of a field.

    len

    Length of data to be read.

    type

    Type to which field data to be read will be converted.

    One of the following field types can be set.

    • FB_CHAR(1)

    • FB_SHORT(2)

    • FB_INT(3)

    • FB_LONG(4)

    • FB_FLOAT(5)

    • FB_DOUBLE(6)

    • FB_STRING(7)

    • FB_CARRAY(8)

  • Return value

    Return value Description

    String

    Function call succeeded.

    NULL

    A specified field key does not exist in a field buffer. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbgetval(), OnFbgetvals(), OnFbgetvali()

4.23. OnFbinit

Initializes a field buffer by calling fbinit().

  • Prototype

    OnFbinit(VARIANT fbuf, VARIANT len)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    len

    Size of a buffer to be initialized.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGetfberrno().

4.24. OnFbinsert

Inserts data to a field with a specified field key and order number in a field buffer, by calling fbinsert().

  • Prototype

    OnFbinsert(VARIANT fbuf, VARIANT fldkey, VARIANT nth, VARIANT value,
           VARIANT fldlen)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    nth

    Order number of a field.

    value

    Data to be inserted.

    fldlen

    Length of data to be inserted.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbdelete(), OnFbupdate()

4.25. OnFbisfbuf

Checks whether a specified field buffer is valid (whether a variable is a buffer allocated by OnFballoc() or OnTpalloc()) by calling fbisfbuf().

  • Prototype

    OnFbisfbuf(VARIANT fbuf)

  • Parameter

    Parameter Description

    fbuf

    Variable to be checked.

  • Return value

    Return value Description

    0

    Function call succeeded.

    1

    A specified field buffer is valid.

  • Related functions

    OnFballoc(), OnTpalloc()

4.26. OnFbispres

Checks whether field data with a specified field key and order number exists by calling fbispres().

  • Prototype

    OnFbispres(VARIANT fbuf, VARIANT fldkey, VARIANT nth)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    nth

    Order number of a field.

  • Return value

    Return value Description

    0

    Function call succeeded.

    1

    Field data with a field key and order number exists.

4.27. OnFbkeynm_unload

Deletes existing data loaded in memory and loads a file set in the FDLFILE environment variable, by calling fbkeynm_unload(). This function is used to load a new FDL file to memory.

  • Prototype

    OnFbkeynm_unload()

  • Related functions

    OnFbnmkey_unload

4.28. OnFbkeyoccur

Returns the number of fields with a specified field key in a field buffer by calling fbkeyoccur().

  • Prototype

    OnFbkeyoccur(VARIANT fbuf, VARIANT fldkey)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

  • Return value

    Return value Description

    The number of fields

    Function call succeeded.

    0

    No field data with a specified field key exists in a field buffer. An error value is obtained by calling OnGettperrno().

    -1

    Function call failed.

4.29. OnFbmake_fldkey

Dynamically creates a field key by calling fbmake_fldkey().

  • Prototype

    OnFbmake_fldkey(VARIANT type, VARIANT no)

  • Parameter

    Parameter Description

    type

    Type of a field to be created. One of the following types can be set.

    • FB_CHAR(1)

    • FB_SHORT(2)

    • FB_INT(3)

    • FB_LONG(4)

    • FB_FLOAT(5)

    • FB_DOUBLE(6)

    • FB_STRING(7)

    • FB_CARRAY(8)

    no

    Number of a field to be created.

  • Return value

    Return value Description

    Field key

    A new field key with a specified type and number was created.

    String

    A field type received through a parameter for a field key to be created already exists.

4.30. OnFbnmkey_unload

Deletes existing data loaded in memory and loads a file set in the FDLFILE environment variable, by calling fbnmkey_unload(). This function is used to load a new FDL file to memory.

  • Prototype

    OnFbnmkey_unload()

  • Related functions

    OnFbkeynm_unload

4.31. OnFbput

Add a field to a field buffer by calling fbput().

  • Prototype

    OnFbput(VARIANT fbuf, VARIANT fldkey, VARIANT value, VARIANT fldlen)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    value

    Data to be added.

    fldlen

    Length of data to be added.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbget(), OnFbputt()

4.32. OnFbputt

Converts data to a specified type, adds a filed to a field buffer, and then saves the data in the field by calling fbputt().

  • Prototype

    OnFbputt(VARIANT fbuf, VARIANT fldkey, VARIANT value, VARIANT len, VARIANT type)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    value

    Data to be added.

    len

    Length of data to be added.

    type

    Type to which data to be saved will be converted.

    One of the following types can be set.

    • FB_CHAR(1)

    • FB_SHORT(2)

    • FB_INT(3)

    • FB_LONG(4)

    • FB_FLOAT(5)

    • FB_DOUBLE(6)

    • FB_STRING(7)

    • FB_CARRAY(8)

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Failed to add a field to a field buffer. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbput()

4.33. OnFbrealloc

Reallocates memory to a field buffer by calling fbget_used().

  • Prototype

    OnFbrealloc(VARIANT fbuf, VARIANT ncount, VARIANT nlen)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    ncount

    Number of fields in which data will be saved.

    nlen

    Total data size. (Unit: bytes)

  • Return value

    Return value Description

    Pointer to allocated memory

    Function call succeeded.

    NULL

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFballoc(), OnTpalloc()

4.34. OnFbstrerror

Returns a field buffer error as a string by calling fbstrerror().

  • Prototype

    OnFbstrerror(VARIANT err_no)

  • Parameter

    Parameter Description

    err_no

    Error value.

  • Return value

    Return value Description

    String

    Function call succeeded.

    NULL

    Function call failed.

  • Related functions

    OnFbcalcsize(), OnTpalloc()

4.35. OnFbtypecvt

Converts field data to a specified type and returns the converted data by calling fbtypecvt().

  • Prototype

    OnFbtypecvt(VARIANT *tolen, VARIANT totype, VARIANT fromval, VARIANT fromtype,
            VARIANT fromlen)

  • Parameter

    Parameter Description

    tolen

    Length of converted data.

    totype

    Type to which original data will be converted.

    fromval

    Original data to be converted.

    fromtype

    Type of original data to be converted.

    fromlen

    Length of original data to be converted.

  • Return value

    Return value Description

    Pointer to converted data

    Function call succeeded.

    NULL

    Failed to convert data. An error value is obtained by calling OnGettperrno().

4.36. OnFbupdate

Converts data with a specified field key and order number in a field buffer by calling fbupdate().

  • Prototype

    OnFbupdate(VARIANT fbuf, VARIANT fldkey, VARIANT nth, VARIANT value,
           VARIANT fldlen)

  • Parameter

    Parameter Description

    fbuf

    Pointer to a buffer allocated by OnTpalloc() or OnFballoc().

    fldkey

    Field key.

    nth

    Order number of a field.

    value

    Data to be converted.

    fldlen

    Length of data to be converted.

  • Return value

    Return value Description

    1

    Function call succeeded.

    -1

    Function call failed. An error value is obtained by calling OnGettperrno().

  • Related functions

    OnFbdelete(), OnFbinsert()

4.37. OnGetfberrno

Returns an error value when an error occurs while a field buffer related API function is executed, by calling getfberrno().

  • Prototype

    OnGetfberrno()

  • Return value

    Value that is currently set in fberror.

  • Related functions

    OnGetfberror()

4.38. OnGetfberror

Returns an error value when an error occurs while a field buffer related API function is executed, by calling getfberror().

  • Prototype

    OnGetfberror()

  • Return value

    Value that is currently set in fberror.

  • Related functions

    OnGetfberrno()

5. Tx Interface Methods

5.1. OnTx_begin

Starts a global transaction by calling tx_begin().

  • Prototype

    OnTx_begin()

  • Return value

    Return value Description

    0

    Function call succeeded.

    Negative value

    Function call failed.

  • Related functions

    OnTx_commit(), OnTx_rollback(), OnTx_set_transaction_timeout()

5.2. OnTx_commit

Commits a global transaction by calling tx_commit().

  • Prototype

    OnTx_commit()

  • Return value

    Return value Description

    0

    Function call succeeded.

    Negative value

    Function call failed.

  • Related functions

    OnTx_begin(), OnTx_rollback(), OnTx_set_transaction_timeout()

5.3. OnTx_rollback

Rolls back a global transaction by calling tx_rollback().

  • Prototype

    OnTx_rollback()

  • Return value

    Return value Description

    0

    Function call succeeded.

    Negative value

    Function call failed.

  • Related functions

    OnTx_begin(), OnTx_commit(), OnTx_set_transaction_timeout()

5.4. OnTx_set_transaction_timeout

Configures timeout for a global transaction by calling tx_set_transaction_timeout().

  • Prototype

    OnTx_set_transaction_timeout(VARIANT timeout)

  • Return value

    Return value Description

    0

    Function call succeeded.

  • Related functions

    OnTx_begin(), OnTx_commit(), OnTx_rollback()

6. Example Program

The following describes an example program that queries, modifies, deletes, and adds office numbers, phone numbers, and addresses with a key of an account number. Filed key buffers are used in the program.

6.1. Program Organization

The example program consists of the following files.

File Description

Tmaxtest.asp

Main screen.

insert.asp

If the [INSERT] button is clicked, a corresponding request will be sent to Tmax and a result of the request will be received and then sent to TmaxTestTx.asp.

update.asp

If the [UPDATE] button is clicked, a corresponding request will be sent to Tmax and a result of the request will be received and then sent to TmaxTestTx.asp.

delete.asp

If the [DELETE] button is clicked, a corresponding request will be sent to Tmax and a result of the request will be received and then sent to TmaxTestTx.asp.

select.asp

If the [SELECT] button is clicked, a corresponding request will be sent to Tmax and a result of the request will be received and then sent to TmaxTestTx.asp.

6.2. Program Description

The following describes each program.

  • Client program

    Item Description

    Tmax library connection

    Tmaxcom.Atmi, Tmaxcom.Etc, Tmaxcom.Fdl, and Tmaxcom.Tx are added.

    Buffer

    'fdl' files need to be created by compiling FIELD KEY buffers and field key files with the fdlc utility.

    Communication

    Synchronous communication is made by using OnTpcall().

    Transaction

    Transactions for queries, modifications, deletions, and additions are handled.

    Tmax connection

    A connection is established whenever a service is executed, and the connection is ended when the service is completed.

  • Server program

    Item Description

    Service

    SELECT, UPDATE, DELETE, and INSERT are written.

    Database

    Oracle database is used. Database information (XA method) is specified in SVRGROUP of a system configuration file.

6.3. Client Program

Main Screen

Run "regsvr32 tmaxcomcli.dll" in Windows command window and then execute the client program. The following screen with [INSERT], [UPDATE], [DELETE], and [SELECT] buttons appears.


I/O Management

The following is an example file for input/output through account numbers.

<Tmaxtest.asp>

<HTML>
<HEAD>
<TITLE> New Document </TITLE>
<META NAME="Generator" CONTENT="EditPlus">
<META NAME="Author" CONTENT="">
<META NAME="Keywords" CONTENT="">
<META NAME="Description" CONTENT="">
</HEAD>
<%
      Dim retStr
      Dim retAccount
      Dim retBranch
      Dim retPhone
      Dim retAddr
      retStr = request("retStr")
      retAccount = request("retAccount")
      retBranch = request("retBranch")
      retPhone = request("retPhone")
      retAddr = request("retAddr")
%>
<script language="javascript">
   function insertPage(){
        var accountValue = document.form1.taccount_id.value;
        var branchValue = document.form1.tbranch_id.value;
        var phoneValue = document.form1.tphone.value;
        var addrValue = document.form1.taddr.value;
        location.href="insert.asp?taccount_id="+accountValue+"&tbranch_id=
                     "+branchValue+"&tphone="+phoneValue+"&taddr="+addrValue;
   }
   function updatePage(){
        var accountValue = document.form1.taccount_id.value;
        var branchValue = document.form1.tbranch_id.value;
        var phoneValue = document.form1.tphone.value;
        var addrValue = document.form1.taddr.value;
        location.href="update.asp?taccount_id="+accountValue+"&tbranch_id=
                      "+branchValue+"&tphone="+phoneValue+"&taddr="+addrValue;
   }
   function deletePage(){
        var accountValue = document.form1.taccount_id.value;
        location.href="delete.asp?taccount_id="+accountValue;
   }
   function selectPage(){
        var accountValue = document.form1.taccount_id.value;
        location.href="select.asp?taccount_id="+accountValue;
   }
</script>
<BODY>
<form action="" name="form1" method="get">
<TABLE>
<TR>
      <TD colspan=2>account number</TD>
      <TD colspan=2><INPUT TYPE="text" NAME="taccount_id"></TD>
</TR>
<TR>
      <TD colspan=2>office number</TD>
      <TD colspan=2><INPUT TYPE="text" NAME="tbranch_id" value="<%if retBranch<> ""
                 then response.write retBranch else response.write "" end if %>">
                 </TD>
</TR>
<TR>
      <TD colspan=2>phone number</TD>
      <TD colspan=2><INPUT TYPE="text" NAME="tphone" value="<%if retPhone<> ""
                 then response.write retPhone else response.write "" end if %>">
                 </TD>
</TR>
<TR>
      <TD colspan=2>address</TD>
      <TD colspan=2><INPUT TYPE="text" NAME="taddr" value="<%if retAddr<> ""
                 then response.write retAddr else response.write "" end if %>"></TD>
</TR>
<TR>
      <TD colspan=2>result value</TD>
      <TD colspan=2><INPUT TYPE="text" NAME="trval" value="<%if retStr<> ""
                 then response.write retStr else response.write "" end if %>"></TD>
</TR>
<TR>
      <TD>
          <INPUT TYPE="button" NAME="insert" value="INSERT" onclick="insertPage();">
      </TD>
      <TD>
          <INPUT TYPE="button" NAME="update" value="UPDATE" onclick="updatePage();">
     </TD>
      <TD >
          <INPUT TYPE="button" NAME="delete" value="DELETE" onclick="deletePage();">
      </TD>
      <TD>
          <INPUT TYPE="button" NAME="select" value="SELECT" onclick="selectPage();">
      </TD>
</TR>
</TABLE></form>

</BODY>
</HTML>
INSERT Button Execution Script

The following is an example file for the [INSERT] button.

<insert.asp>

<%
      Dim file
      Dim label
      Dim tmp
      'Variable used to communicate with Tmax
      Dim fbuf
      'Variable used to read a value that was saved in fbuf in the INSERT service
      Dim retStr
      'Variable used to save a value that was received in TmaxTestTx.asp
      Dim taccount_id
      Dim tranch_id
      Dim tphone
      Dim taddr

      Dim rlen
      Dim rVal
      Dim errno

      'Configuring a value that was received in TmaxTestTx.asp
      taccount_id = request("taccount_id")
      tbranch_id = request("tbranch_id")
      tphone = request("tphone")
      taddr = request("taddr")

      'Creating objects for an ASP interface
      Set objAtmi = Server.CreateObject("Tmaxcom.Atmi")
      Set objFdl = Server.CreateObject("Tmaxcom.Fdl")
      Set objEtc = Server.CreateObject("Tmaxcom.Etc")
      Set objTx = Server.CreateObject("Tmaxcom.Tx")
      ...
      file = "C:\\Inetpub\\wwwroot\\tmax.env"
      label = "TMAXC1"

      'Reading envrionment variables by using OnTmaxreadenv() to access Tmax
      rVal = objEtc.OnTmaxreadenv (file, label)
      if rVal < 0 then
         error processing
         ...
      end if
      'Accessing Tmax by using OnTpstart()
      tmp = ""
      rVal = objAtmi.OnTpstart (tmp, tmp, tmp, tmp, CINT(0))
      if rVal < 0 then
         error processing
         ...
      end if
      'Allocating a buffer by using OnTpalloc()
      'Send buffer/Receive Buffer
      fbuf = objAtmi.OnTpalloc ("FIELD", "", CINT(0))
      'Buffer in which field data will be received
      retStr = objAtmi.OnTpalloc ("STRING", "", CINT(0))

      'Inserting field data to a send buffer
      'INSERT_ID        ((FLDKEY)201327592) /* number: 1000 type: int */
      'BRANCH_ID        ((FLDKEY)201327593) /* number: 1001 type: int */
      'PHONE        ((FLDKEY)469763050) /* number: 1002 type: string */
      'ADDRESS        ((FLDKEY)469763051) /* number: 1003 type: string */
      rVal = objFdl.OnFbput (fbuf, "201327592", taccount_id, CINT("0"))
      if rVal < 0 then
         error processing
         ...
      end if
      rVal = objFdl.OnFbput (fbuf, "201327593", tbranch_id, CINT("0"))
      if rVal < 0 then
         error processing
         ...
      end if
      rVal = objFdl.OnFbput (fbuf, "469763050", tphone, CINT("0"))
      if rVal < 0 then
         error processing
         ...
      end if
      rVal = objFdl.OnFbput (fbuf, "469763051", taddr, CINT("0"))
      if rVal < 0 then
         error processing
         ...
      end if

      'Starting a transaction
      rVal = objTx.OnTx_begin()
      if rVal < 0 then
         error processing
         ...
      end if

      'Requesting an INSERT service to Tmax
      rVal = objAtmi.OnTpcall ("INSERT", fbuf, CINT(0), fbuf, rlen, CINT("0"))
      if rVal < 0 then
         error processing
         ...
        rVal = objTx.OnTx_rollback()
        if rVal < 0 then
           error processing
           ...
        end if
        'Ending a connection to Tmax
        ...
      else
        rVal = objTx.OnTx_commit()
        if rVal < 0 then
           error processing
           ...
        end if
      end if

      'Getting RESULT field data from fbuf, which is a result of OnTpcall()
      'RESULT ((FLDKEY)469764048) /* number: 2000 type: string */
      rVal = objFdl.OnFbget (fbuf, "469764048", retStr, rlen)
      if rVal < 0 then
         error processing
         ...
      end if

      'Getting actual data from a buffer that has RESULT field data
      rVal = objAtmi.OnTpget (retStr, tmp)
      if rVal < 0 then
         error processing
         ...
      end if

      'Releasing buffers
      objAtmi.OnTpfree(fbuf)
      objAtmi.OnTpfree(retStr)

      'Ending a connection to Tmax
      rVal = objAtmi.OnTpend()
      if rVal < 0 then
         error processing
         ...
      end if

      'Releasing objects
      Set objAtmi = nothing
      Set objFdl = nothing
      Set objEtc = nothing
      Set objTx = nothing

      response.redirect "TmaxTestTx.asp?retStr="&tmp
%>
UPDATE Button Execution Script

The following is an example file for the [UPDATE] button.

<update.asp>

<%
      Dim file
      Dim label
      Dim tmp
      'Variable used to communicate with Tmax
      Dim fbuf
      'Variable used to read a value that was saved in fbuf in the UPDATE service
      Dim retStr
      'Variable used to save a value that was received in TmaxTestTx.asp
      Dim taccount_id
      Dim tranch_id
      Dim tphone
      Dim taddr

      Dim rlen
      Dim rVal
      Dim errno

      'Configuring a value that was received in TmaxTestTx.asp
      taccount_id = request("taccount_id")
      tbranch_id = request("tbranch_id")
      tphone = request("tphone")
      taddr = request("taddr")

      'Creating objects for an ASP interface
      Set objAtmi = Server.CreateObject("Tmaxcom.Atmi")
      Set objFdl = Server.CreateObject("Tmaxcom.Fdl")
      Set objEtc = Server.CreateObject("Tmaxcom.Etc")
      Set objTx = Server.CreateObject("Tmaxcom.Tx")
%>
<script language="javascript">
        alert("taccount_id[<%=taccount_id%>] tbranch_id[<%=tbranch_id%>]
               thpone[<%=tphone%>] taddr[<%=taddr%>]");
</script>
<%
      file = "C:\\Inetpub\\wwwroot\\tmax.env"
      label = "TMAXC1"

      'Reading envrionment variables by using OnTmaxreadenv() to access Tmax
      rVal = objEtc.OnTmaxreadenv (file, label)
      if rVal < 0 then
         error processing
         ...
      end if
      'Accessing Tmax by using OnTpstart()
      tmp = ""
      rVal = objAtmi.OnTpstart (tmp, tmp, tmp, tmp, CINT(0))
      if rVal < 0 then
         error processing
         ...
      end if
      'Allocating a buffer by using OnTpalloc()
      'Send buffer/Receive Buffer
      fbuf = objAtmi.OnTpalloc ("FIELD", "", CINT(0))
      'Buffer in which field data will be received
      retStr = objAtmi.OnTpalloc ("STRING", "", CINT(0))

      'Inserting field data to a send buffer
      'UPDATE_ID ((FLDKEY)201327596) /* number: 1004 type: int */
      'BRANCH_ID ((FLDKEY)201327593) /* number: 1001 type: int */
      'PHONE ((FLDKEY)469763050) /* number: 1002 type: string */
      'ADDRESS ((FLDKEY)469763051) /* number: 1003 type: string */
      rVal = objFdl.OnFbput(fbuf, "201327596", taccount_id, CINT("0"))
      if rVal < 0 then
         error processing
         ...
      end if
      rVal = objFdl.OnFbput(fbuf, "201327593", tbranch_id, CINT("0"))
      if rVal < 0 then
         error processing
         ...
      end if
      rVal = objFdl.OnFbput(fbuf, "469763050", tphone, CINT("0"))
      if rVal < 0 then
         error processing
         ...
      end if
      rVal = objFdl.OnFbput(fbuf, "469763051", taddr, CINT("0"))
      if rVal < 0 then
         error processing
         ...
      end if

      'Starting a transaction
      rVal = objTx.OnTx_begin()
      if rVal < 0 then
         error processing
         ...
      end if

      'Requesting an INSERT service to Tmax
      rVal = objAtmi.OnTpcall("UPDATE", fbuf, CINT(0), fbuf, rlen, CINT("0"))
      if rVal < 0 then
         error processing
         ...
         if rVal < 0 then
            errno = objAtmi.OnGettperrno()
            response.write("OnTx_rollback fail["&rVal&"] ["&errno&"]")
         end if
         ...
      else
        rVal = objTx.OnTx_commit()
        if rVal < 0 then
           error processing
           ...
        end if
      end if

      'Getting RESULT field data from fbuf, which is a result of OnTpcall()
      'RESULT ((FLDKEY)469764048) /* number: 2000 type: string */
      rVal = objFdl.OnFbget(fbuf, "469764048", retStr, rlen)
      if rVal < 0 then
         error processing
         ...
      end if

      'Getting actual data from a buffer that has RESULT field data
      rVal = objAtmi.OnTpget (retStr, tmp)
      if rVal < 0 then
         error processing
         ...
      end if

      'Releasing buffers
      objAtmi.OnTpfree(fbuf)
      objAtmi.OnTpfree(retStr)

      'Ending a connection to Tmax
      rVal = objAtmi.OnTpend()
      if rVal < 0 then
         error processing
         ...
      end if

      'Releasing objects
      Set objAtmi = nothing
      Set objFdl = nothing
      Set objEtc = nothing
      Set objTx = nothing

      response.redirect "TmaxTestTx.asp?retStr="&tmp
%>
DELETE Button Execution Script

The following is an example file for the [DELETE] button.

<delete.asp>

<%
      Dim file
      Dim label
      Dim tmp
      'Variable used to communicate with Tmax
      Dim fbuf
      'Variable used to read a value that was saved in fbuf in the INSERT service
      Dim retStr
      'Variable used to save a value that was received in TmaxTestTx.asp
      Dim taccount_id

      Dim rlen
      Dim rVal
      Dim errno

      'Configuring a value that was received in TmaxTestTx.asp
      taccount_id = request("taccount_id")

      'Creating objects for an ASP interface
      Set objAtmi = Server.CreateObject("Tmaxcom.Atmi")
      Set objFdl = Server.CreateObject("Tmaxcom.Fdl")
      Set objEtc = Server.CreateObject("Tmaxcom.Etc")
      Set objTx = Server.CreateObject("Tmaxcom.Tx")
%>
<script language="javascript">
      alert("taccount_id[<%=taccount_id%>]");
</script>
<%
      file = "C:\\Inetpub\\wwwroot\\tmax.env"
      label = "TMAXC1"

      'Reading envrionment variables by using OnTmaxreadenv() to access Tmax
      rVal = objEtc.OnTmaxreadenv (file, label)
      if rVal < 0 then
         error processing
         ...
      end if
      'Accessing Tmax by using OnTpstart()
      tmp = ""
      rVal = objAtmi.OnTpstart (tmp, tmp, tmp, tmp, CINT(0))
      if rVal < 0 then
         error processing
         ...
      end if
      'Allocating a buffer by using OnTpalloc()
      'Send buffer/Receive Buffer
      fbuf = objAtmi.OnTpalloc ("FIELD", "", CINT(0))
      'Buffer in which field data will be received
      retStr = objAtmi.OnTpalloc ("STRING", "", CINT(0))

      'Inserting field data to a send buffer
      'DELETE_ID ((FLDKEY)201327597) /* number: 1005 type: int */
      rVal = objFdl.OnFbput (fbuf, "201327597", taccount_id, CINT("0"))
      if rVal < 0 then
         error processing
         ...
      end if

      'Starting a transaction
      rVal = objTx.OnTx_begin()
      if rVal < 0 then
         error processing
         ...
      end if

      'Requesting a DELETE service to Tmax
      rVal = objAtmi.OnTpcall ("DELETE", fbuf, CINT(0), fbuf, rlen, CINT("0"))
      if rVal < 0 then
         error processing
         ...
         rVal = objTx.OnTx_rollback()
         if rVal < 0 then
            errno = objAtmi.OnGettperrno()
            response.write("OnTx_rollback fail["&rVal&"] ["&errno&"]")
         end if
         ...
      else
         rVal = objTx.OnTx_commit()
         if rVal < 0 then
            error processing
            ...
         end if
      end if

      'Getting RESULT field data from fbuf, which is a result of OnTpcall()
      'RESULT ((FLDKEY)469764048) /* number: 2000 type: string */
      rVal = objFdl.OnFbget (fbuf, "469764048", retStr, rlen)
      if rVal < 0 then
         error processing
         ...
      end if

      'Getting actual data from a buffer that has RESULT field data
      rVal = objAtmi.OnTpget (retStr, tmp)
      if rVal < 0 then
         error processing
         ...
      end if

      'Releasing buffers
      objAtmi.OnTpfree(fbuf)
      objAtmi.OnTpfree(retStr)

      'Ending a connection to Tmax
      rVal = objAtmi.OnTpend()
      if rVal < 0 then
         error processing
         ...
      end if

      'Releasing objects
      Set objAtmi = nothing
      Set objFdl = nothing
      Set objEtc = nothing
      Set objTx = nothing

      response.redirect "TmaxTestTx.asp?retStr="&tmp
%>
SELECT Button Execution Script

The following is an example file for the [SELECT] button.

<select.asp>

<%
      Dim file
      Dim label
      Dim tmp
      'Variable used to communicate with Tmax
      Dim fbuf
      'Variable used to read a value that was saved in fbuf in the INSERT service
      Dim str
      Dim branch
      Dim phone
      Dim addr
      'Variable used to save a value that was received in TmaxTestTx.asp
      Dim taccount_id
      'Variable used to send a value to TmaxTestTx.asp
      Dim retStr
      Dim retBranch
      Dim retPhone
      Dim retAddr

      Dim rlen
      Dim rVal
      Dim errno

      'Configuring a value that was received in TmaxTestTx.asp
      taccount_id = request("taccount_id")

      'Creating objects for an ASP interface
      Set objAtmi = Server.CreateObject("Tmaxcom.Atmi")
      Set objFdl = Server.CreateObject("Tmaxcom.Fdl")
      Set objEtc = Server.CreateObject("Tmaxcom.Etc")
      Set objTx = Server.CreateObject("Tmaxcom.Tx")
%>
<script language="javascript">
      alert("taccount_id[<%=taccount_id%>]");
</script>
<%
      file = "C:\\Inetpub\\wwwroot\\tmax.env"
      label = "TMAXC1"

      'Reading envrionment variables by using OnTmaxreadenv() to access Tmax
      rVal = objEtc.OnTmaxreadenv (file, label)
      if rVal < 0 then
         error processing
         ...
      end if
      'Accessing Tmax by using OnTpstart()
      tmp = ""
      rVal = objAtmi.OnTpstart (tmp, tmp, tmp, tmp, CINT(0))
      if rVal < 0 then
         error processing
         ...
      end if
      'Allocating a buffer by using OnTpalloc()
      'Send buffer/Receive Buffer
      fbuf = objAtmi.OnTpalloc ("FIELD", "", CINT(0))
      'Buffer in which field data will be received
      str = objAtmi.OnTpalloc ("STRING", "", CINT(0))
      branch = objAtmi.OnTpalloc ("STRING", "", CINT(0))
      phone = objAtmi.OnTpalloc ("STRING", "", CINT(0))
      addr = objAtmi.OnTpalloc ("STRING", "", CINT(0))

      'Inserting field data to a send buffer
      'SELECT_ID ((FLDKEY)201327598) /* number: 1006 type: int */
      rVal = objFdl.OnFbput (fbuf, "201327598", taccount_id, CINT("0"))
      if rVal < 0 then
         error processing
         ...
      end if

      'Starting a transaction
      rVal = objTx.OnTx_begin()
      if rVal < 0 then
         error processing
         ...
      end if

      'Requesting a SELECT service to Tmax
      rVal = objAtmi.OnTpcall ("SELECT", fbuf, CINT(0), fbuf, rlen, CINT("0"))
      if rVal < 0 then
         error processing
         ...
         rVal = objTx.OnTx_rollback()
         if rVal < 0 then
            errno = objAtmi.OnGettperrno()
            response.write("OnTx_rollback fail["&rVal&"] ["&errno&"]")
         end if
         ...
      else
        rVal = objTx.OnTx_commit()
        if rVal < 0 then
           error processing
           ...
        end if
      end if

      'Getting RESULT field data from fbuf, which is a result of OnTpcall()
      'RESULT ((FLDKEY)469764048) /* number: 2000 type: string */
      rVal = objFdl.OnFbget (fbuf, "469764048", str, rlen)
      if rVal < 0 then
         error processing
         ...
      end if
      'Getting actual data from a buffer that has RESULT field data
      rVal = objAtmi.OnTpget (str, retStr)
      if rVal < 0 then
         error processing
         ...
      end if
      'BRANCH_ID ((FLDKEY)201327593) /* number: 1001 type: int */
      'PHONE ((FLDKEY)469763050) /* number: 1002 type: string */
      'ADDRESS ((FLDKEY)469763051) /* number: 1003 type: string */
      rVal = objFdl.OnFbget (fbuf, "201327593", branch, rlen)
      rVal = objAtmi.OnTpget(branch, retBranch)
      rVal = objFdl.OnFbget (fbuf, "469763050", phone, rlen)
      rVal = objAtmi.OnTpget(phone, retPhone)
      rVal = objFdl.OnFbget (fbuf, "469763051", addr, rlen)
      rVal = objAtmi.OnTpget(addr, retAddr)

      'Releasing buffers
      objAtmi.OnTpfree(fbuf)
      objAtmi.OnTpfree(str)
      objAtmi.OnTpfree(branch)
      objAtmi.OnTpfree(phone)
      objAtmi.OnTpfree(addr)

      'Ending a connection to Tmax
      rVal = objAtmi.OnTpend()
      if rVal < 0 then
         error processing
         ...
      end if

      'Releasing objects
      Set objAtmi = nothing
      Set objFdl = nothing
      Set objEtc = nothing
      Set objTx = nothing

      response.redirect "TmaxTestTx.asp?retStr="&retStr&"&retBranch="&retBranch&"&
                         retPhone="&retPhone&"&retAddr="&retAddr
%>
