Examples

*DOMAIN
resrc         SHMKEY = 77990, MAXUSER = 256

*NODE
tmax          TMAXDIR = "/home/tmax",
              APPDIR =  "/home/tmax/appbin",
              PATHDIR = "/home/tmax/path",
              TLOGDIR = "/home/tmax/log/tlog",
              ULOGDIR = "/home/tmax/log/slog",
              SLOGDIR = "/home/tmax/log/ulog"

*SVRGROUP
svg1          NODENAME = tmax

*SERVER
syncsvc       SVGNAME = svg1,
              MIN = 1, MAX = 5,
              CLOPT = " –e $(SVR).err –o $(SVR).out "

*SERVICE
TOUPPERSTR    SVRNAME = syncsvc

#include <stdio.h>
#include <string.h>
#include <usrinc/atmi.h>

main(int argc,char *argv[])
{
       char *sendbuf, *recvbuf;
       long rlen;

       if (argc != 2) {
              fprintf(stderr,“Usage: $ %s string \n”,argv[0]);
              exit(1);
       }

       if (tpstart((TPSTART_T*)NULL) == -1) {
              fprintf(stderr,“Tpstart failed\n”);
              exit(1);
       }

       if ((sendbuf = tpalloc(“STRING”,NULL,0)) == NULL) {
              fprintf(stderr,“Error allocation send buffer\n”);
              tpend();
              exit(1);
       }

       if ((recvbuf = tpalloc(“STRING”,NULL,0)) == NULL) {
              fprintf(stderr,“Error allocation recv buffer\n”);
              tpend();
              exit(1);
       }

       strcpy(sendbuf ,argv[ 1 ] ) ;

       if (tpcall(“TOUPPERSTR”,sendbuf,0,&sendbuf,&rlen, TPNOFLAGS) == -1) {
              fprintf(stderr,“Can’t send request to service TOUPPER->%s!\n”,
              tpstrerror(tperrno)) ;
              tpfree(sendbuf) ;
              tpfree(recvbuf) ;
              tpend();
              exit(1);
       }
       printf(“Sent value:%s\n ”,sendbuf );
       printf(“Returned value:%s\n ”,recvbuf );
       tpfree(sendbuf);
       tpfree(recvbuf);
       tpend( );

#include <stdio.h>
#include <usrinc/atmi.h>

TOUPPERSTR(TPSVCINFO *msg)
{
       int i;

       for (i = 0; i < msg->len ; i++)
       msg->data[i] = toupper(msg->data[i]);
       msg->data[i] = ‘\0’;

       tpreturn(TPSUCCESS, 0, msg->data, 0, TPNOFLAGS);
}

struct strdata {
   int flag;
   char sdata[20];
};

*DOMAIN
resrc         SHMKEY = 77990, MAXUSER = 256

*NODE
tmax          TMAXDIR = "/home/tmax",
              APPDIR = "/home/tmax/appbin",
              PATHDIR = "/home/tmax/path"

*SVRGROUP
svg1          NODENAME = tmax

*SERVER
asyncsvc      SVGNAME = svg1, MIN = 1, MAX = 5

*SERVICE
TOUPPER        SVRNAME = asyncsvc
TOLOWER        SVRNAME = asyncsvc

#include <stdio.h>
#include <string.h>
#include <usrinc/atmi.h>
#include “../sdl/demo.s”

main(int argc,char *argv[ ])
{
       struct strdata *sendbuf, *sendbuf1;
       long dlen,clen;
       int cd;

       if (argc != 3) {
              fprintf(stderr, “Usage: $ %s string STRING\n”, argv[0], argv[1]);
              exit(1) ;
       }

       if (tpstart((TPSTART_T *)NULL) == -1) {
              fprintf(stderr, “TPSTART_T failed\n”);
              exit(1) ;
       }

       sendbuf = (struct strdata *)tpalloc(“STRUCT”, “strdata”, 0);
       if ( sendbuf == NULL) {
              fprintf(stderr, “Error allocation send buffer\n”);
              tpend () ;
              exit(1) ;
       }

       sendbuf1 = (struct strdata *)tpalloc(“STRUCT”, “strdata”, 0);
       if (sendbuf1 == NULL) {
              fprintf(stderr, “Error allocation send1 buffer\n”);
              tpend();
              exit(1) ;
       }

       strcpy(sendbuf->sdata, argv[1]);
       strcpy(sendbuf1->sdata, argv[2]);

       if ((cd = tpacall(“TOUPPER”, (char *)sendbuf, 0, TPNOFLAGS)) == -1) {
              fprintf(stderr, “Toupper error -> %s”, tpstrerror(tperrno));
              tpfree((char *)sendbuf);
              tpend();
              exit(1) ;
       }
       if (tpcall(“TOLOWER”,(char *)sendbuf1,0,(char **)&sendbuf1, &dlen,
                               TPSIGRSTRT) == -1) {
              fprintf(stderr, “Tolower error -> %s”, tpstrerror(tperrno));
              tpfree((char *)sendbuf);
              tpend();
              exit(1) ;
       }
       if (tpgetrply(&cd, (char **)&sendbuf, &clen, TPSIGRSTRT) == -1) {
              fprintf(stderr, “Toupper getrply error -> %s”, tpstrerror(tperrno));
              tpfree((char *)sendbuf);
              tpend();
              exit(1) ;
       }
       printf(“Return value %s\n %s\n”, sendbuf -> sdata, sendbuf1 -> sdata);
       tpfree((char *)sendbuf);
       tpfree((char *)sendbuf1);
       tpend() ;
}

#include <stdio.h>
#include <usrinc/atmi.h>
#include “../sdl/demo.s”

TOUPPER(TPSVCINFO *msg)
{
       int i = 0;
       struct strdata *stdata;

       stdata = (struct strdata *)msg -> data;

       while (stdata->sdata[ i ] != ‘\0’) {
       stdata->sdata[ i ] = toupper(stdata->sdata[ i ]);
       i++ ;
       }

       tpreturn(TPSUCCESS, 0, (char *)stdata, 0, TPNOFLAGS);
}

TOLOWER(TPSVCINFO *msg)
{
       int i = 0;
       struct strdata *stdata;

       stdata = (struct strdata *)msg -> data;

       while ( stdata->sdata[ i ] != ‘\0’) {
       stdata->sdata[ i ] = tolower(stdata->sdata[ i ]);
       i++;
       }

       tpreturn(TPSUCCESS, 0, (char *)stdata, 0, TPNOFLAGS);
}

struct sel_o {
    char seqno[10];
    char corpno[10];
    char compdate[8];
    int totmon;
    float guarat;
    float guamon;
} ;

* DOMAIN
resrc        SHMKEY = 77990, MAXUSER = 256

*NODE
tmax          TMAXDIR = “/home/tmax”,
              APPDIR  = “/home/tmax/appbin”,
              PATHDIR =“/home/tmax/path”

* SVRGROUP
svg1          NODENAME = tmax,
              DBNAME = ORACLE,
              OPENINFO = “ORACLE_XA+Acc=P/scott/tiger+SesTm=60”,
              TMSNAME = svg1_tms

*SERVER
convsvc       SVGNAME = svg1, CONV = Y

*SERVICE
MULTI         SVRNAME = convsvc

sqlplus scott/tiger << EOF
create table multi_sel
(
       seqno      VARCHAR(10),
       corpno     VARCHAR(10),
       compdate   VARCHAR(8),
       totmon     NUMERIC(38),
       guarat      FLOAT,
       guamon     FLOAT
);
create unique index idx_tdb on multi_sel(seqno);
EOF

sqlplus scott/tiger << EOF
Desc multi_sel;
select * from multi_sel;
EOF

#include <stdio.h>
#include <usrinc/atmi.h>
#include "../sdl/demo.s"

main(int argc, char *argv[])
{
       struct sel_o *rcvbuf;
       char *sndbuf;
       long sndlen, rcvlen, revent;
       int cd;

       if (argc != 2) {
              printf("Usage: client string\n");
              exit(1);
       }

       /* connects to Tmax with tpstart(). */
       if (tpstart((TPSTART_T *) NULL) == -1) {
              printf("tpstart failed\n");
              exit(1);
       }

       if ((sndbuf = tpalloc("STRING", NULL, 12)) == NULL) {
              printf("tpalloc failed:sndbuf\n");
              tpend();
              exit(1);
       }

       if ((rcvbuf = (struct sel_o *)tpalloc("STRUCT", "sel_o", 0)) == NULL) {
              printf("tpalloc failed:rcvbuf\n");
              tpfree(sndbuf);
              tpend();
              exit(1);
       }
       strcpy(sndbuf, argv[1]);

       if ((cd = tpconnect ("MULTI", sndbuf, 0, TPRECVONLY)) == -1){
              printf("tpconnect failed:CONVER service, tperrno=%d\n", tperrno);
              tpfree(sndbuf);
              tpfree((char *)rcvbuf);
              tpend();
              exit(1);
       }

      /* interactive communication connection, The interaction control is sent
         to a server. */
       printf("tpconnect SUCESS \"MULTI\" service\n");
       while ( 1 ) {    /* receives multiple data */
              printf("tprecv strat\n");
              if( tprecv(cd, (char **)&rcvbuf, &rcvlen, TPNOTIME, &revent) < 0 ) {
              /* If ends with tpreturn() in a server */
              if (revent == TPEV_SVCSUCC){
                     printf("all is completed\n");
                     break;
              }
              printf("tprecv failed, tperrno=%s, revent=%x\n",
              tpstrerror(tperrno), revent );
              tpfree(sndbuf);
              tpfree((char *)rcvbuf);
              tpend();
              exit(1);
       }
       printf("seqno = %s\t\t corpno =%s\n", rcvbuf->seqno, rcvbuf->corpno);
       printf("compdate = %s\t\t totmon =%d\n", rcvbuf->compdate, rcvbuf->totmon);
       printf("guarat = %f\t\t guamon =%f\n\n\n", rcvbuf->guarat, rcvbuf->guamon) ;
}
       tpfree(sndbuf);
       tpfree((char *)rcvbuf);
       tpend();
       printf("FINISH\n");
}

#include <stdio.h>
#include <string.h>
#include <usrinc/atmi.h>
#include “../sdl/demo.s”

EXEC SQL begin declare section; /* Oracle global variables declaration */
       char seq[10];
       struct sel_o *sndbuf;
EXEC SQL end declare section;
EXEC SQL include sqlca;

MULTI(TPSVCINFO *msg)
{
       int i, cd;
       long sndlen, revent;

       memset(seq, 0, 10);
       strcpy(seq, msg->data);

       if ((sndbuf = (struct sel_o *) tpalloc (“STRUCT”, “sel_o”, 0)) == NULL) {
               printf(“tpalloc failed:\n”);
               tpreturn (TPFAIL, -1, NULL, 0, TPNOFLAGS);
       }

       /* declares a cursor for large amount of data */
       EXEC SQL declare democursor cursor for
       select *
       from corp
       where seqno > :seq;

       EXEC SQL open democursor;
       EXEC SQL whenever not found goto end_of_fetch;
       if (sqlca.sqlcode != 0){
              printf(“oracle sqlerror=%s”, sqlca.sqlerrm.sqlerrmc);
              tpreturn (TPFAIL, sqlca.sqlcode, NULL, 0, TPNOFLAGS);
       }

        /* sends data while there is no Oracle error */
       while ( sqlca.sqlcode == 0 ){
              EXEC SQL fetch democursor into :sndbuf;

              if (tpsend (msg->cd, (char *)sndbuf, 0, TPNOTIME, &revent) == -1){
                     printf(“tpsend failed, tperrno=%d, revent=%x\n”, tperrno,
                              revent ) ;
                     tpfree ((char *)sndbuf);
                     tpreturn (TPFAIL, -1, NULL, 0, TPNOFLAGS);
              }
       }

       tpreturn (TPFAIL, sqlca.sqlcode, NULL, 0, TPNOFLAGS);

       end_of_fetch:
       exec sql close democursor;
       printf(“tpreturn before”);
       tpreturn (TPSUCCESS, 0, NULL, 0, TPNOFLAGS);
}

struct ktran {
    int no;
    char name[20];
};

*DOMAIN
resrc             SHMKEY = 77990, MAXUSER = 256

*NODE
tmax              TMAXDIR = /home/tmax,
                  APPDIR = /home/tmax/appbin,
                  PATHDIR = /home/tmax/path

*SVRGROUP
svg1              NODENAME = tmax,
                  DBNAME = ORACLE,
                  OPENINFO = “Oracle_XA+Acc=P/scott/tiger+SesTm=60”,
                  TMSNAME = svg1_tms

*SERVER
oinssvc           SVGNAME = svg1, MIN = 1, MAX = 5

*SERVICE
ORAINS            SVRNAME = oinssvc

sqlplus scott/tiger << EOF
       create table testdb1 (
       no number(7),
       name char(30)
) ;
EOF

sqlpus scott/tiger << EOF
desc testdb1;
select * from testdb1;
select count (*) from testdb1;
EOF

#include <stdio.h>
#include <usrinc/atmi.h>
#include “../sdl/demo.s”

main(int argc, char *argv[])
{
       struct ktran *sndbuf, *rcvbuf;
       long sndlen, rcvlen;
       int cd;

       if (argc != 3) {
       printf(“Usage: client no name\n”);
              exit(1);
       }

       printf(“tpstart-start \n”);
       if(tpstart ((TPSTART_T *) NULL) == -1) {
              printf(“Tpstart failed\n”);
              exit(1);
       }
       printf(“tpstart-ok \n”);

       if((sndbuf=(struct ktran *) tpalloc("STRUCT","ktran",0))==NULL) {
            printf(“tpalloc failed:sndbuf, tperrno=%d\n”, tperrno);
            tpend();
            exit(1) ;
        }

        if((rcvbuf = (struct ktran *) tpalloc("STRUCT", "ktran", 0))== NULL) {
             printf(“tpalloc failed:rcvbuf, tperrno=%d\n”, tperrno);
             tpfree((char *)sndbuf);
             tpend();
             exit(1);
        }

       sndbuf->no = atoi(argv[1]);
       strcpy(sndbuf->name, argv[2]);
       printf(“tpcall-start \n”);
       tx_begin();

       if(tpcall("ORAINS",(char *)sndbuf,0,(char **)&rcvbuf,&rcvlen,TPNOFLAGS)==-1){
            printf(“tpcall failed:ORA service, tperrno=%d”, tperrno);
            printf(“sql code=%d\n”, tpurcode);
            tx_rollback();
            tpfree ((char *)sndbuf);
            tpfree ((char *)rcvbuf);
            tpend();
            exit(1);
       }

       printf(“tpcall-success \n”);
       tx_commit();

       tpfree ((char *)sndbuf);
       tpfree ((char *)rcvbuf);
       tpend();
}

#include <stdio.h>
#include <usrinc/atmi.h>
#include “../sdl/demo.s”

EXEC SQL begin declare section;
char name[20];
int no;

EXEC SQL end declare section;
EXEC SQL include sqlca;

ORAINS(TPSVCINFO *msg)
{
       struct ktran *stdata;
        stdata = (struct ktran *)msg->data;
        strcpy(name, stdata->name);
        no = stdata->no;
        printf(“Ora service started\n”);

       /* inserts into a database */
       EXEC SQL insert into testdb1(no, name) values(:no, :name);

       if (sqlca.sqlcode != 0){
             printf(“oracle sqlerror=%s”,sqlca.sqlerrm.sqlerrmc);
             tpreturn (TPFAIL, sqlca.sqlcode, NULL, 0, TPNOFLAGS);
        }

       tpreturn (TPSUCCESS, sqlca.sqlcode, stdata, 0, TPNOFLAGS);
}

struct stru_his{
       long    ACCOUNT_ID ;
       long    TELLER_ID ;
       long    BRANCH_ID ;
       long    AMOUNT ;
} ;

*DOMAIN
resrc             SHMKEY = 77990, MAXUSER = 256

*NODE
tmax              TMAXDIR =“/home/tmax”,
                  APPDIR =“/home/tmax/appbin”,
                  PATHDIR =“/home/tmax/path”

*SVRGROUP
svg1              NODENAME = tmax,
                  DBNAME = ORACLE,
                  OPENINFO = “Oracle_XA+Acc=P/scott/tiger+SesTm=600”,
                  TMSNAME = svg1_tms

*SERVER
oselsvc           SVGNAME = svg1, MIN = 1, MAX = 5

*SERVICE
ORASEL            SVRNAME = oselsvc

OPENINFO=“Oracle_XA+Acc=P/account/password +SesTm=60+LogDir=/tmp+DbgFl=0x01”

sqlplus scott/tiger << EOF
       create table sel_his(
       account_id number(6),
       teller_id number(6),
       branch_id number(6),
       amount number(6)
);
create unique index idx_tdb1 on sel_his(account_id);
EOF

sqlplus scott/tiger << EOF
desc sel_his;
select * from sel_his;
EOF

#include <stdio.h>
#include <usrinc/atmi.h>
#include <usrinc/tx.h>
#include “../sdl/demo.s”
#define NARRAY 10
#define NOTFOUND 1403

main(int argc,char *argv[])
{
       struct stru_his *transf;
       int i, j;
       long urcode, nrecv, narray = NARRAY;
       long account_id, teller_id, branch_id, amount;

       if (argc != 2) {
              fprintf(stderr,“Usage:$%s ACOUNT_ID !\n”, argv[0]);
              exit(0);
       }

       if (tpstart((TPSTART_T *) NULL) == -1) {    /* connects to Tmax */
           fprintf(stderr,“TPSTART_T(tpinfo) failed -> %s!\n”,
           tpstrerror(tperrno)) ;
           exit(1) ;
       }

       /* creates a c structure buffer */
       transf = (struct stru_his *) tpalloc(“STRUCT”, “stru_his”,0);
       if (transf == (struct stru_his *)NULL) {
              fprintf(stderr,“Tpalloc failed->%s!\n”,
              tpstrerror(tperrno)) ;
              tpend();
              exit(1);
       }
       memset(transf, 0x00, sizeof(struct stru_his));

       account_id = atoi(argv[1]);
       transf->ACCOUNT_ID = account_id;

       /* sets transaction timeout */
       tx_set_transaction_timeout(30);

       /* starts global transactions */
       if (tx_begin() < 0) {
              fprintf(stderr, “tx_begin() failed ->%s!\n”,
              tpstrerror(tperrno));
              tpfree((char*)transf);
              tpend();
              exit(0) ;
       }

       if (tpcall(“ORASEL”,(char *)transf, 0, (char **)&transf, &nrecv,
                  TPNOFLAGS)== -1){
              /* request the“ORASEL” service with synchronous communication */
              fprintf(stderr,“Tpcall(SELECT...)error->%s ! ”,
              tpstrerror(tperrno)) ;
              tpfree((char *)transf);
              /* cancels a transaction if failed */
              tx_rollback();
              tpend();
              exit(0) ;
       }
       /* commits a transaction if successful */
       if (tx_commit() == -1) {
              fprintf(stderr, “tx_commit() failed ->%s!\n”,
              tpstrerror(tperrno)) ;
              tpfree((char *)transf);
                     tpend();
                     exit(0) ;
       }
        /* Received data is an array of a struct. */
       for (j =0 ; j < tpurcode ; j++) {
              /* prints data selected by Oracle */
              if (j == 0)
                     printf(“%-12s%-10s%-10s%-10s\n”,
                    “ACCOUNT_ID”,“TELLER_ID”, “BRANCH_ID”, “AMOUNT”);
              account_id=transf[j].ACCOUNT_ID;
              teller_id=transf[j].TELLER_ID;
              branch_id=(*(transf+j)).BRANCH_ID;
              amount=transf[j].AMOUNT;
       printf(“%-12d %-10d %-10d %-10d\n”, account_id, teller_id,branch_id, amount);
       }
       /* if there is no selected data or it is the end */
       if (urcode == NOTFOUND) {
       printf(“No records selected!\n”);
              tpfree((char *)transf);
              tpend();
              return 0;
}
       tpfree((char *)transf);
       tpend();
}

#include <stdio.h>
#include <usrinc/atmi.h>
#include “../sdl/demo.s”
#define NARRAY 10
#define TOOMANY 2112
#define NOTFOUND 1403
EXEC SQL include sqlca.h;

EXEC SQL begin declare section;
       long key, rowno= NARRAY;
       long account_id[NARRAY],teller_id[NARRAY], branch_id[NARRAY],
       amount[NARRAY] ;
EXEC SQL end declare section;

ORASEL(TPSVCINFO *msg)
{
       struct stru_his *transf;
       int i , lastno;
       transf=(struct stru_his *) msg->data;

       /* transfers contents of the msg buffer to a program variable */
       key = transf->ACCOUNT_ID;

        /* adjusts the size of the transf buffer */
       if((transf=(struct stru_his *) tprealloc((char*)transf,
           sizeof(struct stru_his) * NARRAY ))==(struct stru_his*)NULL){
              fprintf(stderr, “tprealloc error ->%s\n”,
              tpstrerror(tperrno));
              tpreturn(TPFAIL, tperrno, NULL, 0, TPNOFLAGS);
       }

       EXEC SQL select account_id, teller_id, branch_id, amount
                  into :account_id, :teller_id, :branch_id, :amount  from sel_his
                 where account_id > :key
              /* puts data that has account_id greater than the key value sent */
              order by account_id;       /* by a client to a global variable */

       /* sql error check (excludes non-selected or too many data) */
       if (sqlca.sqlcode!=0 && sqlca.sqlcode!=NOTFOUND && sqlca.sqlcode!=TOOMANY) {
              fprintf(stderr,“SQL ERROR ->NO(%d):%s\n”, sqlca.sqlcode,
              sqlca.sqlerrm.sqlerrmc) ;
              tpreturn(TPFAIL, sqlca.sqlcode, NULL, 0, TPNOFLAGS);
       }

       /* puts the number of access to lastno */
       lastno = sqlca.sqlerrd[2];

       /* too many selected data */
       if (sqlca.sqlcode == TOOMANY)
              lastno =rowno;

       /* No records */
       if (lastno == 0)
              transf->ACCOUNT_ID = 0;

        /* puts data selected by Oracle to a buffer to be sent */
        for ( i = 0 ; i < lastno; i++) {
              transf[i].ACCOUNT_ID = account_id[i];
              transf[i].TELLER_ID = teller_id[i];
              transf[i].BRANCH_ID = branch_id[i];
              transf[i].AMOUNT = amount[i];
       }
       tpreturn(TPSUCCESS, lastno, transf, i * sizeof(struct stru_his),
       TPNOFLAGS );
}

struct info {
     char seq[8];
     char data01[128];
     char data02[128];
     char data03[128];
};

*DOMAIN
resrc            SHMKEY = 77990, MAXUSER = 256

*NODE
tmax             TMAXDIR =”/home/tmax”, A
                 APPDIR =”/home/tmax/appbin”,
                 PATHDIR =”/home/tmax/path”

*SVRGROUP
svg1             NODENAME = tmax,
                 DBNAME = INFORMIX,
                 OPENINFO = “stores7”,
                 CLOSEINFO = “”,
                 TMSNAME = info_tms

*SERVER
tdbsvr          SVGNAME = svg1, MIN = 1, MAX = 5

*SERVICE
INSERT         SVRNAME = tdbsvr

dbaccess << EOF
create database stores7 with buffered log;
grant connect to public;

database stores7;
drop table testdb1;
create table testdb1 (
        seq        VARCHAR(8) ,
        data01     VARCHAR(120) ,
        data02     VARCHAR(120) ,
        data03     VARCHAR(120)
) lock mode row;

create unique index idx_tdb1 on testdb1(seq);
EOF

dbaccess << EOF
database stores7;
select * from testdb1;
EOF

#include <stdio.h>
#include <usrinc/atmi.h>
#include <usrinc/tx.h>
#include “info.s”
main(int argc, char **argv)
{
       struct info *transf;
       char data[256];
       long nrecv;

       /* connects to Tmax. */
       if ((tpstart((TPSTART_T *)NULL) == -1) {
            fprintf(stderr, “tpstart(TPINFO...) failed ->%s!\n”,
            tpstrerror(tperrno)) ;
            exit(1) ;
       }

      /* allocates buffer memory to be used in an application program. */
     if ((transf=(struct info *)tpalloc ("STRUCT","info",0))==(struct info *)NULL){
          fprintf(stderr, “tpalloc(struct info, ...) failed ->%s!\n”,
          tpstrerror(tperrno)) ;
          tpend();
          exit(1) ;
       }

       /* fills the data fields to be transferred. */
       strcpy(transf->seq, “000001”);
       strcpy(transf->data01, “Hello”);
       strcpy(transf->data02, “World”);
       strcpy(transf->data03, “1234”);

        /* sets transaction timeout * /
       tx_set_transaction_timeout (30);

       /* informs of the beginning of a transaction */
       if (tx_begin() < 0) {
              fprintf(stderr, “tx_begin() failed ->%s!\n”,
              tpstrerror(tperrno)) ;
              tpfree ((char *)transf);
              tpend( ); exit(0);
       }

       /* calls a service */
     if (tpcall ("INSERT",(char*) transf,0,(char **)&transf,&nrecv,TPNOFLAGS)==-1) {
         fprintf(stderr,"tpcall(struct info, ...)
         failed ->%s!\n",tpstrerror(tperrno)) ;
         tx_rollback ();
         tpfree ((char *)transf),
         tpend();
          exit(0);
       }

      /* Transactions are complete. */
     if (tx_commit () < 0) {
          fprintf(stderr, “tx_commit() failed ->%s!\n”, tpstrerror(tperrno)) ;
          tpfree ((char *)transf);
          tpend( );
          exit(0);
       }

       tpfree ((char *)transf );
       /* disconnects from Tmax. */
       tpend( ) ;
}

#include <stdio.h>
#include <ctype.h>
#include <usrinc/atmi.h>
#include “info.s”

EXEC SQL include sqlca.h;

/* service name*/
INSERT(TPSVCINFO *msg)
{
      /* declares a buffer type for the program */
      struct info *INFO;

       /* declares a buffer type for SQL statements */
       EXEC SQL begin declare section;
       varchar seq[8],buf01[128],buf02[128],buf03[128];
       EXEC SQL end declare section;

       /* receives data in a struct format from the message buffer */
       INFO = (struct info *)msg -> data;

       /* copies data received in a struct format to a database buffer */
       strcpy(seq, INFO->seq);
       strcpy(buf01, INFO->data01);
       strcpy(buf02, INFO->data02);
       strcpy(buf03, INFO->data03);

      /* performs an Insert SQL statement */
       EXEC SQL insert into testdb1 (seq,data01,data02,data03)
       values(:seq, :buf01, :buf02, :buf03);

      /* if an error occurs */
       if ( sqlca.sqlcode ! = 0)  {
             /* informs Insert is failed */
              printf(“SQL error => %d !” ,sqlca.sqlcode);
              tpreturn (TPFAIL, sqlca.sqlcode, NULL, 0, TPNOFLAGS);
       }

       /* when Insert successfully completes */
       tpreturn (TPSUCCESS, 0, NULL, 0, TPNOFLAGS);
}

struct stru_acct {
    int  ACCOUNT_ID;
    char PHONE[20];
    char ADDRESS[80];
};

*DOMAIN
resrc         SHMKEY = 77990, MAXUSER = 256

*NODE
tmax          TMAXDIR =”/home/tmax”,
              APPDIR =”/home/tmax/appbin”,
              PATHDIR =”/home/tmax/path”

*SVRGROUP
svg1          NODENAME = tmax,
              DBNAME = INFORMIX,
              OPENINFO = “stores7”,
              CLOSEINFO = “”,
              TMSNAME = info_tms
*SERVER
SEL_ACCT      SVGNAME = svg1, MIN = 1, MAX = 5

*SERVICE
SEL_ACCT      SVRNAME = sel_acct

dbaccess << EOF
create database stores7 with buffered log;
grant connect to public;

database stores7;
drop table ACCOUNT;

create table ACCOUNT (
       account_id INTEGER,
       phone VARCHAR(20),
       address VARCHAR(80)
) lock mode row;

create unique index idx_tdb1 on ACCOUNT(account_id);
EOF

dbaccess << EOF
database stores7;
select * from ACCOUNT;
EOF

#include <stdio.h>
#include <time.h>
#include <usrinc/atmi.h>
#include <usrinc/tx.h>
#include “acct.s”
#define NOTFOUND 1403

void htime(char *, int *);

main(int argc, char *argv[ ])
{
       struct stru_acct *transf;
       float tps;
       int i, j, loop, cnt_data = 0, sec1, sec2;
       long urcode, nrecv, narray;
       char ts[30], te[30], phone[20], address[80];
       int account_id, key;

       if(argc != 2) {
          fprintf(stderr,“Usage:$%sLOOP (NARRAY = 30) !\n”, argv[0]);
          exit(0) ;
       }

       /*repeats the loop as many as times a user wants*/
       loop = atoi(argv[1]);

        /* connects to Tmax */
       if (tpstart((TPSTART_T *)NULL) == -1) {
           fprintf(stderr, “tpstart(tpinfo) failed ->%s!\n”,
           tpstrerror(tperrno));
           exit(1) ;
       }

      /* sec1 = start time */
       htime(ts,&sec1); key=0;

      /* allocates a message buffer */
     for( i = 0; i < loop; i++) {
         if ((transf=(struct stru_acct *)tpalloc("STRUCT","stru_acct",0))==(struct stru_acct *)NULL) {
               fprintf(stderr,“Tpalloc(STRUCT.. )failed->%s!\n” ,
               tpstrerror(tperrno)) ;
                tpend(); exit(1);
          }
         transf -> ACCOUNT_ID = key;

         /* time-out value= 30 */
         tx_set_transaction_timeout(30) ;

         if (tx_begin() < 0) { /* starts transactions */
              fprintf(stderr, “tx_begin() failed ->%s!\n”, tpstrerror(tperrno)) ;
              tpfree((char*)transf);
              tpend();
              exit(0);
       }

       /* calls a select service */
       if (tpcall(“SEL_ACCT”, (char *)transf, 0, (char **)&transf, &nrecv, TPNOFLAGS)== -1) {
           //* service error: the message buffer is freed, the transaction is
                             cancelled, and the connection is terminated */
            fprintf(stderr,“Tpcall(SELECT...)error->%s! ” ,
                      tpstrerror(tperrno)) ;
            tpfree ((char *)transf);
            tx_rollback ( ) ;
            tpend( ) ;
            exit ( 1 ) ;
       }
       urcode = tpurcode;

      /*The service is successfully completed.
         The actual resource is changed as a result of the transaction */
       if (tx_commit() < 0 ) {
              fprintf(stderr, “tx_commit() failed ->%s!\n”, tpstrerror(tperrno)) ;
              tpfree((char *)transf);
              tpend();
              exit(0);
       }

      /*if data is selected*/
      if ( urcode != NOTFOUND) {
           narray =urcode;
           /* the last record of selected data */
           key=transf[narray-1].ACCOUNT_ID;
          /* outputs results to a user as many as the number of selected data */
          for ( j = 0 ; j < narray ; j++ ) {
               if ( j == 0)
                   printf(“%-10s%-14s%s\n”, “ACCOUNT_ID”, “PHONE”,“ADDRESS”) ;
                   account_id = transf[j].ACCOUNT_ID;
                   strcpy(phone, transf[j].PHONE);
                   strcpy(address, transf[j].ADDRESS);
                   printf(“%-10d %-14s %s\n”, account_id, phone, address);
            }/* for2 end */

           /* increases the number of results */
           cnt_data += j;

           /* message buffer free */
           tpfree ((char *)transf);
            if(urcode == NOTFOUND) {
               printf(“No records selected!\n”);
               break ;
             }
       }/* for1 end */

       /* message buffer free */
       tpfree ((char *)transf);
       /* disconnects from Tmax */
       tpend ();

       /* sec2 = end time */
       htime(te,&sec2);

       /* calculates processing time for each data */
       printf(“TOT.COUNT = %d\n”, cnt_data);
       printf(“Start time = %s\n”, ts);
       printf(“End time = %s\n”, te);
      if ((sec2-sec1) ! = 0)
           tps = (float) cnt_data / (sec2 - sec1);
       else
           tps = cnt_data;
       printf(“Interval = %d secs ==> %10.2f T/S\n”, sec2-sec1,tps);
}

htime(char *cdate, int *sec)
{
       long time(), timef, pt;
        char ct[20], *ap;
        struct tm *localtime(), *tmp;

        pt = time(&timef);
        *sec = pt;
        tmp = localtime(&timef);
        ap = asctime(tmp);

        sscanf(ap, “%*s%*s%*s%s”,ct);
        sprintf( cdate, “%02d. %02d. %02d %s”, tmp->tm_year, ++tmp->tm_mon,
                 tmp->tm_mday,ct);
}

#include <stdio.h>
#include <usrinc/atmi.h>
#include <usrinc/tx.h>
#include “acct.s”
#define NFETCH 5
#define NOTFOUND 100

EXEC SQL include sqlca.h;
EXEC SQL begin declare section;
long account_id, key;
varchar phone[20], address[80];
EXEC SQL end declare section;

SEL_ACCT(TPSVCINFO *msg)
{
       int i , j , nfetch;
       int return_code;
       struct stru_acct *ACCT_V;

       /*receives client data. */
       ACCT_V = (struct stru_acct *) msg->data;

       /* moves an accound ID value to be selected to the key */
       key = ACCT_V->ACCOUNT_ID;

       /* reallocates the size of the client buffer*/
       if ((ACCT_V = (struct stru_acct *)tprealloc((char *)ACCT_V,
           sizeof(struct stru_acct)*NFETCH )) == (struct stru_acct *)NULL) {
           fprintf(stderr, “tprealloc error =%s\n”, tpstrerror(tperrno));
           tpreturn (TPFAIL, tperrno, NULL, 0, TPNOFLAGS);
       }

       /*initializes a buffer*/
       ACCT_V->ACCOUNT_ID = 0;
       strcpy(ACCT_V->PHONE,“ ” ) ;
       strcpy(ACCT_V->ADDRESS,“ ” ) ;

       /* extracts phone and address fields from the ACCOUNT table */
       EXEC SQL declare CUR_1 cursor for
                 select account_id,phone,address
                  into :account_id, :pfone, :address
                  from ACCOUNT
               where account_id > :key;/* if an account ID is larger than
                                                              a field key */

       /* cursor open */
       EXEC SQL open CUR_1;
       /* cursor open error */
       if (sqlca.sqlcode ! = 0) {
              printf(“open cursor error !\n”);
              tpreturn(TPFAIL, sqlca.sqlcode, NULL, 0, TPNOFLAGS);
       }

       nfetch=0 ;
       return_code = NOTFOUND;

       /* cursor open success */
       while (sqlca.sqlcode == 0) {
           /* fetches data from the location a cursor points one at a time */
           EXEC SQL fetch CUR_1;

           /* fetch error */
           if (sqlca.sqlcode ! = 0) {
               if (sqlca.sqlcode == NOTFOUND)
                    break ;
                break ;
            }

           ACCT_V[nfetch].ACCOUNT_ID = account_id;
           strcpy(ACCT_V[nfetch].PHONE, phone );
           strcpy(ACCT_V[nfetch].ADDRESS, address );

            /* increases the number of selected data */
            nfetch++;
            return_code = nfetch

            /* exits from "while"
              if data is selected as many as the number of NFETCH */
           if (nfetch > NFETCH) {
               nfetch = NFETCH;
               return_code = nfetch;
               break ;
            }
       }
       /* cursor close */
       EXEC SQL close CUR_1;

       /* returns the result and its data to a client */
       tpreturn ( TPSUCCESS, return_code, (char *)ACCT_V,
                  sizeof(struct stru_acct)*nfetch, TPNOFLAGS);
}

*DOMAIN
tmax1           SHMKEY = 71990, MINCLH = 1, MAXCLH = 3,
                TPORTNO = 7789, BLOCKTIME = 30,
                MAXCPC = 150

*NODE
phk        TMAXDIR = "/home/tmaxha/tmax",
                APPDIR  = "/home/tmaxha/tmax/appbin",
                PATHDIR = "/home/tmaxha/tmax/path",
                TLOGDIR = "/home/tmaxha/tmax/log/tlog",
                ULOGDIR = "/home/tmaxha/tmax/log/ulog",
                SLOGDIR = "/home/tmaxha/tmax/log/slog"

*SVRGROUP
xa_svg_db2      NODENAME = "phk",
                  DBNAME = IBMDB2,
#                 XAOPTION = "DYNAMIC XASWITCH32",
                  XAOPTION = "DYNAMIC",
                  OPENINFO = "db=test,uid=tmaxha,pwd=ha0115",
                  TMSNAME = tms_db2,
                  RESTART=N

*SERVER
svr_db2                  SVGNAME = xa_svg_db2

*SERVICE
XASERVICE2         SVRNAME = svr_db2

# Execute 'db2start'
$ db2start

# Create a database named 'TPTEST'
$ db2 "CREATE DATABASE TPTEST"

# Connect to the TPTEST database
$ db2 "CONNECT TO TPTEST"

# Create an EMP table
$ db2 -vf create.ers -t

<create.ers>
CREATE TABLE EMP (
         EMPNO                  DECIMAL(8) NOT NULL,
         ENAME                  VARCHAR(16),
         JOB                    VARCHAR(16),
         SAL                    DECIMAL(8),
         HIREDATE               DECIMAL(8),
         XID                    CHAR(32)
);

# Check whether the EMP table is successfully created.
$ db2 "LIST TABLES"

#include <stdio.h>
#include <unistd.h>
#include <stdlib.h>
#include <string.h>
#include <usrinc/atmi.h>

int main(int argc, char *argv[])
{
         char         *sndbuf, *rcvbuf;
         long         rcvlen;
         int         ret;

         if ( (ret = tmaxreadenv( "tmax.env","TMAX" )) == -1 ){
                  printf( "tmax read env failed.[%s]\n", tpstrerror(tperrno));
                  exit(1);
         }

         if (tpstart((TPSTART_T *)NULL) == -1){
                  printf("tpstart failed.[%s]\n", tpstrerror(tperrno));
                  exit(1);
         }

         if ((sndbuf = (char *)tpalloc("STRING", NULL, 0)) == NULL) {
                  printf("sendbuf alloc failed! [%s]\n", tpstrerror(tperrno));
                  tpend();

                  exit(1);
         }

         if ((rcvbuf = (char *)tpalloc("STRING", NULL, 0)) == NULL) {
                  printf("recvbuf alloc failed! [%s]\n", tpstrerror(tperrno));
                  tpfree(sndbuf);
                  tpend();

                  exit(1);
         }

         strcpy(sndbuf, argv[1]);

         ret = tx_begin();
         if (ret < 0) {
                  printf("tx_begin is failed.[%s]\n", tpstrerror(tperrno));
                  resource_free(sndbuf, rcvbuf);

                  exit(1);
         } else
                  printf("tx_begin success.\n");

         if (tpcall("XASERVICE2", sndbuf, strlen(sndbuf), &rcvbuf, &rcvlen, 0) == -1){
                  printf("Can't send request to service XASERVICE2.[%s]\n", tpstrerror(tperrno));
                  ret = tx_rollback();
                  if (ret < 0)
                      printf("tx_rollback is failed. [%s]\n", tpstrerror(tperrno));

                  resource_free(&sndbuf, &rcvbuf);
                  exit(1);
         } else
                  printf("XASERVCE2 success.\n");

         ret = tx_commit();
         if (ret < 0) {
               printf("tx_commit is failed. [%s]\n", tpstrerror(tperrno));
               ret = tx_rollback();
               if (ret < 0)
                    printf("tx_rollback is failed. [%s]\n", tpstrerror(tperrno));
         } else
               printf("tx_commit success.\n");
         resource_free(sndbuf, rcvbuf);
         return 0;
}

resource_free(char* sndbuf, char *rcvbuf)
{
         if (rcvbuf != NULL)
             tpfree((char*)rcvbuf);
         if (sndbuf != NULL)
             tpfree((char*)sndbuf);
         tpend();
}

#include <stdio.h>
#include <usrinc/atmi.h>

EXEC SQL INCLUDE SQLCA;

EXEC SQL begin declare section;
         sqlint32 h_empno;
         sqlint32 h_count;
EXEC SQL end declare section;

XASERVICE2(TPSVCINFO *msg)
{
         char         *res_msg;
         int  h_count=0;

          h_empno = atoi(msg->data);
         printf("h_empno = %d \n", h_empno);

         EXEC SQL
                  INSERT into EMP (EMPNO) VALUES (:h_empno);
         if (sqlca.sqlcode != 0) {
              printf("insertion is failed : sqlcode[%d]%d\n", sqlca.sqlcode, sqlca.sqlstate);
              tpreturn(TPFAIL, -1, 0, 0, 0);
         } else
               EXEC SQL SELECT COUNT(*)
               INTO    :h_count
               FROM    emp
               WHERE   empno = :h_empno;
               if (sqlca.sqlcode != 0) {
                   printf("insertion is failed : sqlcode[%d]%d\n", sqlca.sqlcode, sqlca.sqlstate);
                   tpreturn(TPFAIL, -1, 0, 0, 0);
               } else
                    printf("insertion is success. selcnt(%d) \n", h_count);

           tpreturn(TPSUCCESS, 0, 0, 0, 0);
}

# Server makefile for DB2
# Linux 64bit

DB2LIBDIR = $(DB2_HOME)/lib
DB2LIBS           = -ldb2

DB         = TEST
DB2USER = tmaxha
DB2PASS = ha0115

TARGET  = $(COMP_TARGET)
APOBJS  = $(TARGET).o
APOBJS2  = utilemb.o
NSDLOBJ = $(TMAXDIR)/lib64/sdl.o

#OBJS    = $(APOBJS) $(APOBJS2) $(SVCTOBJ)
OBJS    = $(APOBJS)  $(SVCTOBJ)
SVCTOBJ = $(TARGET)_svctab.o

#CFLAGS  = -m64 -O -I$(TMAXDIR) -I$(DB2_HOME)/include
CFLAGS  =  -O -I$(TMAXDIR) -I$(DB2_HOME)/include
LDFLAGS =

TMAXAPPDIR  = $(TMAXDIR)/appbin
TMAXSVCTDIR = $(TMAXDIR)/svct
TMAXLIBDIR  = $(TMAXDIR)/lib64

TMAXLIBS    = -lsvr -ldb2s          # dynmic XAOPTION=DYNAMIC (DB2 Client v8.0(below) 32bit  or  DB2 Client 64bit & Windows)
#TMAXLIBS    = -lsvr -ldb2_64s      # dynmic XAOPTION=DYNAMIC (DB2 Client v8.0(below) 64bit & Linux/Unix)
#TMAXLIBS    = -lsvr -ldb2s_static  #static XAOPTION=none (DB2 Client v9.0(above))
#
.SUFFIXES : .c

.c.o:
         $(CC) $(CFLAGS) $(LDFLAGS) -c $<

#
# server compile
#
all: $(TARGET)

$(TARGET): $(OBJS)
         $(CC) $(CFLAGS) $(LDFLAGS) -L$(TMAXLIBDIR) -o $(TARGET) -L$(DB2LIBDIR) $(DB2LIBS) $(OBJS) $(TMAXLIBS) $(NSDLOBJ)
         mv $(TARGET) $(TMAXAPPDIR)
         rm -f $(OBJS)

$(APOBJS): $(TARGET).sqc
         db2 connect to $(DB) user $(DB2USER) using $(DB2PASS)
         db2 prep $(TARGET).sqc bindfile
         db2 bind $(TARGET).bnd
         db2 connect reset
         db2 terminate
         $(CC) $(CFLAGS) $(LDFLAGS) -c $(TARGET).c

$(SVCTOBJ):
         cp -f $(TMAXSVCTDIR)/$(TARGET)_svctab.c .
         touch ./$(TARGET)_svctab.c
         $(CC) $(CFLAGS) -c ./$(TARGET)_svctab.c

#
clean:
         :-rm -f *.o core $(TMAXAPPDIR)/$(TARGET) $(TARGET).bnd

# TMS Makefile for DB2
# Linux 64bit

TARGET  = tms_db2
APOBJ   = dumy.o

APPDIR  = $(TMAXDIR)/appbin
TMAXLIBD= $(TMAXDIR)/lib64
TMAXLIBS    = -lsvr -ldb2s          # dynmic XAOPTION=DYNAMIC (DB2 Client v8.0(below) 32bit  or  DB2 Client 64bit & Windows)
#TMAXLIBS    = -lsvr -ldb2_64s      # dynmic XAOPTION=DYNAMIC (DB2 Client v8.0(below) 64bit & Linux/Unix)
#TMAXLIBS    = -lsvr -ldb2s_static  #static XAOPTION=none (DB2 Client v9.0(above))

DB2PATH = $(DB2_HOME)
DB2LIBDIR= $(DB2PATH)/lib
DB2LIB  = -ldb2

CFLAGS  =
LDFLAGS =
SYSLIBS =

all: $(TARGET)

$(TARGET): $(APOBJ)
         $(CC) $(CFLAGS) $(LDFLAGS) -o $(TARGET) -L$(TMAXLIBD) $(TMAXLIBS) $(APOBJ) -L$(DB2LIBDIR) $(DB2LIB) $(SYSLIBS)
         mv $(TARGET) $(APPDIR)/.

$(APOBJ):
         $(CC) $(CFLAGS) -c dumy.c
#
clean:
         -rm -f *.o core $(APPDIR)/$(TARGET)

*DOMAIN
tmax1         SHMKEY=@SHMEMKY@,
              MINCLH=1,
              MAXCLH=1,
              TPORTNO=@TPORTNO@,
              BLOCKTIME=5,
              TXTIME=10,
              RACPORT=@TRACPORT@,
              MAXCPC = 150
*NODE
@HOSTNAME@      TMAXDIR = "@TMAXDIR@",
                APPDIR  = "@TMAXDIR@/appbin",
                PATHDIR = "@TMAXDIR@/path",
                TLOGDIR = "@TMAXDIR@/log/tlog",
                ULOGDIR = "@TMAXDIR@/log/ulog",
                SLOGDIR = "@TMAXDIR@/log/slog"

*SVRGROUP
svg1        NODENAME = "@HOSTNAME@", DBNAME = MQ,
               OPENINFO = "QMNAME=MQTEST",
               TMSNAME  = tms_mq
*SERVER
mq_xa        SVGNAME = svg1, CLOPT = "-- -m MQTEST -q ORANGE.LOCAL.QUEUE"

*SERVICE
# Common PUT/GET
PUTQ1        SVRNAME = mq_xa
GETQ1        SVRNAME = mq_xa

psx2@mqm:/opt/mqm/samp/bin>amqsput ORANGE.LOCAL.QUEUE MQTEST
Sample AMQSPUT0 start
target queue is ORANGE.LOCAL.QUEUE
test
Sample AMQSPUT0 end

qpsx2@mqm:/opt/mqm/samp/bin>amqsget ORANGE.LOCAL.QUEUE MQTEST
Sample AMQSGET0 start
message <test>

qpsx2@mqm:/opt/mqm/samp/bin>amqsgbr ORANGE.LOCAL.QUEUE MQTEST
Sample AMQSGBR0 (browse) start
MQTEST
Messages for ORANGE.LOCAL.QUEUE
1 <test>
no more messages
Sample AMQSGBR0 (browse) end

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <time.h>
#include <usrinc/atmi.h>
#include <usrinc/tmaxapi.h>
#include <usrinc/ucs.h>
#include <usrinc/fbuf.h>
#include <usrinc/tx.h>
#include "../sdl/demo_sdl.h"
#include "../fdl/demo_fdl.h"

#define SVCNAME1 "PUTQ1"

int carray_db(str sndbuf, char *rcvbuf, int flag, int iud);

char   myname[100];

main(int argc, char *argv[])
{
         int    in_num;
         int    i, ret, empno, loop_cnt, ins_flag;
         str    sndbuf;
         char   *rcvbuf;
         long   rcvlen;
         int    flags;

         if (argc != 4) {
         printf("Usage: %s empno loop_cnt ins_flag \n", argv[0]);
         printf("flag : 1|0 \n");
         exit(1);
         }

         if ((ret = tmaxreadenv("tmax.env","TMAX")) == -1) {
         printf("<%-15s> tmaxreadenv fail [%s]\n", __FILE__, tpstrerror(tperrno));
         exit(1);
         }

         if ( tpstart((TPSTART_T *)NULL) == -1 ){
         printf("<%-15s> tpstart fail [%s]\n", __FILE__, tpstrerror(tperrno));
         exit(1);
         }

         sndbuf=(str)tpalloc("CARRAY", NULL, 4096);
         if(sndbuf==NULL) {
         printf("<%-15s> tpalloc fail [%s]\n", __FILE__, tpstrerror(tperrno));
         tpend();
         exit(1);
         }

         rcvbuf=(char *)tpalloc("STRING", NULL, 4096);
         if(rcvbuf==NULL) {
         printf("<%-15s> tpalloc fail [%s]\n", __FILE__, tpstrerror(tperrno));
         tpend();
         exit(1);
         }

         strcpy(myname, argv[0]);
         empno = atoi(argv[1]);
         loop_cnt = atoi(argv[2]);
         ins_flag = atoi(argv[3]);

         sndbuf->empno = empno;
         sndbuf->sal   = V_SAL;
         strcpy(sndbuf->ename, V_ENAME);
         strcpy(sndbuf->job, V_JOB);
         strcpy(sndbuf->date, V_HIREDATE);

    for (i=1; i<=loop_cnt; i++)
    {
        printf("\n LOOP COUNT = %d \n", i);

         if (ins_flag == 1)
         {
                  flags = INSERT;

                  printf(">> INSERT : ROLLBACK TEST \n");
                  carray_db (sndbuf, rcvbuf, ROLLBACK, flags);

                  printf(">> INSERT : COMMIT TEST \n");
                  carray_db (sndbuf, rcvbuf, COMMIT, flags);
         }
    }
         tpfree((char *)sndbuf);
         tpfree((char *)rcvbuf);
         tpend();
}

int carray_db(str sndbuf, char *rcvbuf, int flag, int iud)
{
         int ret, cd;
         long rlen;

         ret = tx_begin();
        if(ret < 0)
        {
                  printf("<%-15s> tx_begin fail [%s]\n", __FILE__, tpstrerror(tperrno));
                  exit(1);
        }

        if(iud == INSERT)
                strcpy(sndbuf->svcname01, SVCNAME1);
        else
        {
                  printf("[%s] flags must be INSERT or UPDATE or DELETE\n", myname);
                  exit(1);
        }
         cd = tpcall(sndbuf->svcname01, (char *)sndbuf, sizeof(struct temp_str), (char **)&rcvbuf, (long *)&rlen, 0 );
        if(cd < 0)
        {
                  printf("<%-15s> tpcall [%s]\n", __FILE__, tpstrerror(tperrno));
                  tx_rollback();
                  exit(1);
        }

         printf("[%s] [%s]\n", myname, rcvbuf);

         if(flag == COMMIT)
         {
         ret = tx_commit();
                 if(ret < 0)
                {
                  printf("<%-15s> tx_commit fail [%s]\n", __FILE__, tpstrerror(tperrno));
                  exit(1);
                 }
         } else {
         ret = tx_rollback();
                 if(ret < 0)
                {
                  printf("<%-15s> tx_rollback fail [%s]\n", __FILE__, tpstrerror(tperrno));
                  exit(1);
                  }
         }
         return 0;
}

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <time.h>
#include <usrinc/atmi.h>
#include <usrinc/tmaxapi.h>
#include <usrinc/ucs.h>
#include <usrinc/fbuf.h>
#include <usrinc/tx.h>
#include "../sdl/demo_sdl.h"
#include "../fdl/demo_fdl.h"

#define SVCNAME1 "GETQ1"

int carray_db(str sndbuf, char *rcvbuf, int flag, int iud);
char   myname[100];

main(int argc, char *argv[])
{
         int    in_num;
         int    i, ret, empno, loop_cnt, ins_flag;
         str    sndbuf;
         char   *rcvbuf;
         long   rcvlen;
         int    flags;

         if (argc != 4) {
                  printf("Usage: %s empno loop_cnt ins_flag \n", argv[0]);
         printf("flag : 1|0 \n");
         exit(1);
         }

         if ((ret = tmaxreadenv("tmax.env","TMAX")) == -1) {
         printf("<%-15s> tmaxreadenv fail [%s]\n", __FILE__, tpstrerror(tperrno));
         exit(1);
         }

         if ( tpstart((TPSTART_T *)NULL) == -1 ){
         printf("<%-15s> tpstart fail [%s]\n", __FILE__, tpstrerror(tperrno));
         exit(1);
         }

         sndbuf=(str)tpalloc("CARRAY", NULL, 4096);
         if(sndbuf==NULL) {
         printf("<%-15s> tpalloc fail [%s]\n", __FILE__, tpstrerror(tperrno));
         tpend();
         exit(1);
         }

         rcvbuf=(char *)tpalloc("STRING", NULL, 4096);
         if(rcvbuf==NULL) {
         printf("<%-15s> tpalloc fail [%s]\n", __FILE__, tpstrerror(tperrno));
         tpend();
         exit(1);
         }

         strcpy(myname, argv[0]);
         empno = atoi(argv[1]);
         loop_cnt = atoi(argv[2]);
         ins_flag = atoi(argv[3]);

         sndbuf->empno = empno;
         sndbuf->sal   = V_SAL;
         strcpy(sndbuf->ename, V_ENAME);
         strcpy(sndbuf->job, V_JOB);
         strcpy(sndbuf->date, V_HIREDATE);

    for (i=1; i<=loop_cnt; i++)
    {
        printf("\n LOOP COUNT = %d \n", i);

         if (ins_flag == 1)
         {
                  flags = INSERT;

                  printf(">> INSERT : ROLLBACK TEST \n");
                  carray_db (sndbuf, rcvbuf, ROLLBACK, flags);

                  printf(">> INSERT : COMMIT TEST \n");
                  carray_db (sndbuf, rcvbuf, COMMIT, flags);
         }
    }
         tpfree((char *)sndbuf);
         tpfree((char *)rcvbuf);
         tpend();
}

int carray_db(str sndbuf, char *rcvbuf, int flag, int iud)
{
         int ret, cd;
         long rlen;

         ret = tx_begin();
        if(ret < 0)
        {
                  printf("<%-15s> tx_begin fail [%s]\n", __FILE__, tpstrerror(tperrno));
                  exit(1);
        }

        if(iud == INSERT)
                strcpy(sndbuf->svcname01, SVCNAME1);
        else
        {
                  printf("[%s] flags must be INSERT or UPDATE or DELETE\n", myname);
                  exit(1);
        }
         cd = tpcall(sndbuf->svcname01, (char *)sndbuf, sizeof(struct temp_str), (char **)&rcvbuf, (long *)&rlen, 0 );
        if(cd < 0)
        {
                  printf("<%-15s> tpcall [%s]\n", __FILE__, tpstrerror(tperrno));
                  tx_rollback();
                  exit(1);
        }

         printf("[%s] [%s]\n", myname, rcvbuf);

         if(flag == COMMIT)
         {
         ret = tx_commit();
                 if(ret < 0)
                {
                  printf("<%-15s> tx_commit fail [%s]\n", __FILE__, tpstrerror(tperrno));
                  exit(1);
                 }
         } else {
         ret = tx_rollback();
                 if(ret < 0)
                {
                  printf("<%-15s> tx_rollback fail [%s]\n", __FILE__, tpstrerror(tperrno));
                  exit(1);
                  }
         }

         return 0;
}

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <cmqc.h>
#include <getopt.h>
#include <usrinc/atmi.h>
#include <usrinc/tmaxapi.h>
#include <usrinc/fbuf.h>
#include <usrinc/tx.h>
#include "../sdl/demo_sdl.h"
#include "../fdl/demo_fdl.h"

#define MQ_CSP_PASSWORD_LENGTH         256

MQHCONN  Hcon;                   /* connection handle             */
MQHOBJ   Hobj;                   /* object handle                 */
char     QMName[50];             /* queue manager name            */
char     QName[50];              /* queue name                    */
MQOD     od = {MQOD_DEFAULT};    /* Object Descriptor             */
MQLONG   OpenCode = MQCC_FAILED; /* MQOPEN completion code        */
MQLONG   CReason;                /* reason code for MQCONNX       */

int tpsvrinit(int argc, char **argv)
{
         /*   Declare MQI structures needed                                */
         MQCNO   cno = {MQCNO_DEFAULT};   /* connection options            */
         MQCSP   csp = {MQCSP_DEFAULT};   /* security parameters           */
         MQLONG   O_options;              /* MQOPEN options                */
         MQLONG   CompCode;               /* completion code               */
         MQLONG   Reason;                 /* reason code                   */
         char    *UserId = NULL;          /* UserId for authentication     */
         char     Password[MQ_CSP_PASSWORD_LENGTH + 1] = {0}; /* For auth  */
         int                  c;

         strcpy(QMName, "QM1");
         strcpy(QName, "Q1");

         opterr = 0;
         while ((c = getopt(argc, argv, "m:q:u:p:")) != EOF) {
                  switch (c) {
                           case 'm':
                                    strcpy(QMName, optarg);
                                    break;
                           case 'q':
                                    strcpy(QName, optarg);
                                    break;
                           case 'u':
                                    UserId = optarg;
                                    break;
                           case 'p':
                                    strcpy(Password, optarg);
                                    break;
                           case '?':
                           default:
                                    break;
                  }
         }

         if (UserId != NULL) {
                  cno.SecurityParmsPtr = &csp;
                  cno.Version = MQCNO_VERSION_5;

                  csp.AuthenticationType = MQCSP_AUTH_USER_ID_AND_PWD;
                  csp.CSPUserIdPtr = UserId;
                  csp.CSPUserIdLength = strlen(UserId);
                  csp.CSPPasswordPtr = Password;
                  csp.CSPPasswordLength = strlen(csp.CSPPasswordPtr);
         }

         MQCONNX(QMName,                 /* queue manager                  */
                  &cno,                  /* connection options             */
                  &Hcon,                 /* connection handle              */
                  &CompCode,             /* completion code                */
                  &CReason);             /* reason code                    */
         if (CompCode == MQCC_FAILED) {
                  printf("MQCONNX ended with reason code %d\n", CReason);
                  return -1;
         } else if (CompCode == MQCC_WARNING) {
                  printf("MQCONNX generated a warning with reason code %d\n", CReason);
                  printf("Continuing...\n");
         }

         strncpy(od.ObjectName, QName, (size_t)MQ_Q_NAME_LENGTH);
         printf("target queue is %s\n", od.ObjectName);

#if 0
         if (argc > 5)
         {
                  strncpy(od.ObjectQMgrName, argv[5], (size_t) MQ_Q_MGR_NAME_LENGTH);
                  printf("target queue manager is %s\n", od.ObjectQMgrName);
         }

         if (argc > 6)
         {
                  strncpy(od.DynamicQName, argv[6], (size_t) MQ_Q_NAME_LENGTH);
                  printf("dynamic queue name is %s\n", od.DynamicQName);
         }
#endif

         /*   Open the target message queue for output                   */
         O_options = MQOO_OUTPUT            /* open queue for output     */
                  | MQOO_INPUT_AS_Q_DEF     /* open queue for input      */
                  | MQOO_FAIL_IF_QUIESCING  /* but not if MQM stopping   */
                  ;                         /* = 0x2010 = 8208 decimal   */

         MQOPEN(Hcon,                       /* connection handle           */
                  &od,                      /* object descriptor for queue */
                  O_options,                /* open options                */
                  &Hobj,                    /* object handle               */
                  &OpenCode,                /* MQOPEN completion code      */
                  &Reason);                 /* reason code                 */
         if (Reason != MQRC_NONE) {
                  printf("MQOPEN ended with reason code %d\n", Reason);
         }
         if (OpenCode == MQCC_FAILED) {
                  printf("unable to open queue for output\n");
         }
         return 0;
}

int tpsvrdone()
{
         MQLONG   C_options;              /* MQCLOSE options              */
         MQLONG   CompCode;               /* completion code              */
         MQLONG   Reason;                 /* reason code                  */

         /*   Close the target queue (if it was opened)                   */
         if (OpenCode != MQCC_FAILED) {
                  C_options = MQCO_NONE;     /* no close options          */
                  MQCLOSE(Hcon,              /* connection handle         */
                           &Hobj,            /* object handle             */
                           C_options,
                           &CompCode,        /* completion code           */
                           &Reason);         /* reason code               */

                  /* report reason, if any     */
                  if (Reason != MQRC_NONE) {
                           printf("MQCLOSE ended with reason code %d\n", Reason);
                  }
         }

         /*   Disconnect from MQM if not already connected                 */
         if (CReason != MQRC_ALREADY_CONNECTED) {
                  MQDISC(&Hcon,               /* connection handle         */
                           &CompCode,         /* completion code           */
                           &Reason);          /* reason code               */

                  /* report reason, if any     */
                  if (Reason != MQRC_NONE) {
                           printf("MQDISC ended with reason code %d\n", Reason);
                  }
         }
         return 0;
}

PUTQ1(TPSVCINFO *msg)
{
         MQMD     md = {MQMD_DEFAULT};    /* Message Descriptor            */
         MQPMO   pmo = {MQPMO_DEFAULT};   /* put message options           */
         MQLONG   CompCode;               /* completion code               */
         MQLONG   Reason;                 /* reason code                   */

         str  sndbuf;
         char *rcvbuf;
         char tmp[1024];

         sndbuf = (str)msg->data;
         rcvbuf=(char *)tpalloc("STRING", NULL, 4096);
        if(rcvbuf==NULL) {
                printf("tpalloc failed (rcvbuf) : %s\n", tpstrerror(tperrno));
                  tpreturn(TPFAIL, -1, NULL, 0, 0);
        }

         memcpy(md.Format,           /* character string format            */
                  MQFMT_STRING, (size_t)MQ_FORMAT_LENGTH);

         pmo.Options = MQPMO_SYNCPOINT
                  | MQPMO_FAIL_IF_QUIESCING;
         /* pmo.Options |= MQPMO_NEW_MSG_ID;                           */
         /* pmo.Options |= MQPMO_NEW_CORREL_ID;                        */

         memcpy(md.MsgId, MQMI_NONE, sizeof(md.MsgId) );

         MQPUT(Hcon,                /* connection handle               */
                  Hobj,             /* object handle                   */
                  &md,              /* message descriptor              */
                  &pmo,             /* default options (datagram)      */
                  msg->len,         /* message length                  */
                  sndbuf->job,      /* message buffer                  */
                  &CompCode,        /* completion code                 */
                  &Reason);         /* reason code                     */
         if (Reason != MQRC_NONE) {
                  printf("MQPUT ended with reason code %d\n", Reason);
         }
         if (CompCode != MQCC_FAILED) {
                  sprintf(tmp, "[%s] MQPUT Success", msg->name);
                  strcpy(rcvbuf, tmp);
                  tpreturn(TPSUCCESS, 0, rcvbuf, strlen(rcvbuf), 0);
         }
         else{
                  sprintf(tmp, "[%s] MQPUT Fail", msg->name);
                  strcpy(rcvbuf, tmp);
                  tpreturn(TPFAIL, 0, tmp, strlen(rcvbuf), 0);
         }
}

GETQ1(TPSVCINFO *msg)
{
         MQMD     md = {MQMD_DEFAULT};    /* Message Descriptor            */
         MQGMO   gmo = {MQGMO_DEFAULT};   /* get message options           */
         MQLONG   messlen;                /* message length                */
         MQLONG   CompCode;               /* completion code               */
         MQLONG   Reason;                 /* reason code                   */
         char *rcvbuf;
         long rcvlen;

         rcvbuf=(char *)tpalloc("STRING", NULL, 4096);
        if(rcvbuf==NULL) {
                printf("tpalloc failed (rcvbuf) : %s\n", tpstrerror(tperrno));
                  tpreturn(TPFAIL, -1, NULL, 0, 0);
        }

         /*gmo.Version = MQGMO_VERSION_2;*/ /* Avoid need to reset Message */
         /*gmo.MatchOptions = MQMO_NONE; */ /* ID and Correlation ID after */
         /* every MQGET                 */
         gmo.Options = MQGMO_WAIT         /* wait for new messages       */
                  | MQPMO_SYNCPOINT
                  | MQGMO_CONVERT;        /* convert if necessary        */
         gmo.WaitInterval = 15000;        /* 15 second limit for waiting */

         rcvlen = 4096 -1; /* buffer size available for GET   */

         memcpy(md.MsgId, MQMI_NONE, sizeof(md.MsgId));
         memcpy(md.CorrelId, MQCI_NONE, sizeof(md.CorrelId));
         md.Encoding       = MQENC_NATIVE;
         md.CodedCharSetId = MQCCSI_Q_MGR;

         MQGET(Hcon,                  /* connection handle                 */
                  Hobj,               /* object handle                     */
                  &md,                /* message descriptor                */
                  &gmo,               /* get message options               */
                  rcvlen,             /* buffer length                     */
                  rcvbuf,             /* message buffer                    */
                  &messlen,           /* message length                    */
                  &CompCode,          /* completion code                   */
                  &Reason);           /* reason code                       */

         /* report reason, if any     */
         if (Reason != MQRC_NONE) {
                if (Reason == MQRC_NO_MSG_AVAILABLE) {   /* special report for normal end    */
                    printf("no more messages\n");
                } else {                      /* general report for other reasons */
                    printf("MQGET ended with reason code %d\n", Reason);

                     /* treat truncated message as a failure for this sample */
                    if (Reason == MQRC_TRUNCATED_MSG_FAILED) {
                        CompCode = MQCC_FAILED;
                    }
               }
         }

         if (CompCode != MQCC_FAILED)
             tpreturn(TPSUCCESS, 0, rcvbuf, rcvlen, 0);
         else
             tpreturn(TPFAIL, 0, NULL, 0, 0);
}

# Server MQ makefile LInux 32bit

TARGET         = $(COMP_TARGET)
APOBJS         = $(TARGET).o
NSDLOBJ = $(TMAXDIR)/lib/sdl.o

#MQLIB = -lmqm           # Server for C
#MQLIB = -lmqm_r         # Server for C for threaded
#MQLIB = -lmqmxa         # Server XA interface
#MQLIB = -lmqmxa_r       # Server XA interface for threaded

#LIBS    = -lsvr -lmqs -lmqmxa -lmqm         # for non-threaded
LIBS    = -lsvr -lmqs -lmqmxa_r -lmqm_r      # for threaded
OBJS    = $(APOBJS) $(SVCTOBJ)
SVCTOBJ = $(TARGET)_svctab.o

#CFLAGS  = -O -I$(TMAXDIR) -I$(HOME)/include -L$(HOME)/lib -I$(MQ_HOME)/inc
CFLAGS  = -m32 -O -I$(TMAXDIR)  -I$(MQ_HOME)/inc

APPDIR  = $(TMAXDIR)/appbin
SVCTDIR = $(TMAXDIR)/svct
TMAXLIBDIR  = $(TMAXDIR)/lib

MQLIBD         = $(MQ_HOME)/lib

#
.SUFFIXES : .c

.c.o:
         $(CC) $(CFLAGS) -c $<

#
# server compile
#
all: $(TARGET)

$(TARGET): $(OBJS)
         $(CC) $(CFLAGS) -L$(TMAXLIBDIR) -L$(MQLIBD) -o $(TARGET) $(OBJS) $(LIBS) $(NSDLOBJ)
         mv $(TARGET) $(APPDIR)/.
         rm -f $(OBJS)

$(SVCTOBJ):
         cp -f $(SVCTDIR)/$(TARGET)_svctab.c .
         touch ./$(TARGET)_svctab.c
         $(CC) $(CFLAGS) -c ./$(TARGET)_svctab.c

#
clean:
         -rm -f *.o core $(APPDIR)/$(TARGET) $(TARGET).lis

# TMS Makefile for MQ
# Linux 32bit

MQLIBDIR = $(MQ_HOME)/lib
#MQLIB = -lmqmxa         # Server XA interface
MQLIB = -lmqmxa_r        # Server XA interface for threaded

TARGET  = tms_mq
APOBJ   = dumy.o

APPDIR  = $(TMAXDIR)/appbin
TMAXLIBD= $(TMAXDIR)/lib
TMAXLIBS= -ltms -lmqs

CFLAGS  = -m32
LDFLAGS =
SYSLIBS =

all : $(TARGET)

$(TARGET): $(APOBJ)
         $(CC) $(CFLAGS) $(LDFLAGS) -o $(TARGET) -L$(TMAXLIBD) $(TMAXLIBS) $(APOBJ) -L$(MQLIBDIR) $(MQLIB)
         mv $(TARGET) $(APPDIR)/.

$(APOBJ):
         $(CC) $(CFLAGS) -c dumy.c
#
clean:
         -rm -f *.o core $(APPDIR)/$(TARGET)

struct input {
        int     account_id;
        int     branch_id;
        char    phone[15];
        char    address[61];
};

*DOMAIN
res   SHMKEY=88000, MINCLH=1, MAXCLH=5, TPORTNO=8880, BLOCKTIME=60

*NODE
tmax          TMAXDIR = "/user/ tmax ",
              APPDIR  = "/user/ tmax /appbin",
              PATHDIR = "/user/ tmax /path",
              TLOGDIR = "/user/ tmax /log/tlog",
              ULOGDIR="/user/ tmax /log/ulog",
              SLOGDIR="/user/ tmax /log/slog"

*SVRGROUP
svg1          NODENAME = tmax, DBNAME = ORACLE,
              OPENINFO = "ORACLE_XA+Acc=P/bmt/bmt+SesTm=60",
              TMSNAME = svg1_tms

*SERVER
update        SVGNAME=svg1
insert        SVGNAME=svg1

*SERVICE
UPDATE        SVRNAME=update
INSERT        SVRNAME=insert

[tmax]
TMAX_HOST_ADDR=192.168.1.39
TMAX_HOST_PORT=8880
SDLFILE=/user/tmax/sample/sdl/tmax.sdl
TMAX_CONNECT_TIMEOUT=5

#include <stdio.h>
#include <usrinc/atmi.h>
#include "../sdl/demo.s"

#define TEMP_PHONE "6283-2114"
#define TEMP_ADDRESS "Korea"

int main(int argc, char *argv[])
{
        struct input *sndbuf;
        char    *rcvbuf;
        int acnt_id, n, timeout;
        long    len;

        if (argc != 2) {
            fprintf(stderr, "Usage:%s account_id \n", argv[0]);
            exit(1);
        }

        acnt_id = atoi(argv[1]);
        timeout = 5;

        n = tmaxreadenv("tmax.env", "tmax");
        if (n < 0) {
            fprintf(stderr, "tmaxreadenv fail! tperrno = %d\n", tperrno);
            exit(1);
        }

        n = tpstart((TPSTART_T *)NULL);
        if (n < 0) {
            fprintf(stderr, "tpstart fail! tperrno = %s\n", tperrno);
            exit(1);
        }

        sndbuf = (struct input *)tpalloc("STRUCT", "input", `
                  sizeof(struct input));
        if (sndbuf == NULL) {
            fprintf(stderr, "tpalloc fail: sndbuf tperrno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        rcvbuf = (char *)tpalloc("STRING", NULL, 0);
        if (rcvbuf == NULL) {
            fprintf(stderr, "tpalloc fail: rcvbuf tperrno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        sndbuf->account_id = acnt_id;
        sndbuf->branch_id = acnt_id;
        strcpy(sndbuf ->phone, TEMP_PHONE);
        strcpy(sndbuf ->address, TEMP_ADDRESS);

        tx_set_transaction_timeout(timeout);
        n = tx_begin();
        if (n < 0)
            fprintf(stderr, "tx begin fail! tperrno = %d\n", tperrno);

        n = tpcall("UPDATE", (char *)sndbuf, sizeof(struct input),
                   (char **)&rcvbuf, (long *)&len, TPNOFLAGS);
        if (n < 0) {
            fprintf(stderr, "tpcall fail! tperrno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        n = tx_commit();
        if (n < 0) {
            fprintf(stderr, "tx commit fail! tx error = %d \n", n);
            tx_rollback();
            tpend();
            exit(1);
        }

        printf("rtn msg = %s\n", rcvbuf);
        tpfree((char *)sndbuf);
        tpfree((char *)rcvbuf);
        tpend();
}

#include <stdio.h>
#include <ctype.h>
#include <usrinc/atmi.h>
#include <usrinc/sdl.h>
#include "../sdl/demo.s"

#define OKMSG "YOU COMPLETE THE TRANSACTION"

EXEC SQL include sqlca.h;
EXEC SQL BEGIN DECLARE SECTION;
        int     account_id;
        int     branch_id;
        char    ssn[15];
        char    phone[15];
        char    address[61];
EXEC SQL END DECLARE SECTION;

UPDATE(TPSVCINFO *msg)
{
        struct input *rcvbuf;
        int     ret;
        long    acnt_id, rcvlen;
        char    *send;

        rcvbuf = (struct input *)(msg->data);
            send = (char *)tpalloc("STRING", NULL, 0);
        if (send == NULL) {
            fprintf(stderr, "tpalloc fail errno = %s\n", strerror(tperrno));
            tpreturn(TPFAIL, 0, (char *)NULL, 0, 0);
        }
        account_id = rcvbuf->account_id;
        branch_id = rcvbuf->branch_id;
}

#include <stdio.h>
#include <ctype.h>
#include <usrinc/atmi.h>
#include <usrinc/sdl.h>
#include "../sdl/demo.s"

#define OKMSG "YOU COMPLETE THE TRANSACTION"

EXEC SQL include sqlca.h;
EXEC SQL BEGIN DECLARE SECTION;
        int     account_id;
        int     branch_id;
        char    ssn[15];
        char    phone[15];
        char    address[61];
EXEC SQL END DECLARE SECTION;

INSERT(msg)
TPSVCINFO  *msg;
{
        struct input *rcvbuf;
        int     ret;
        long    acnt_id;
        char    *send;

        rcvbuf = (struct input *)(msg->data);
        send = (char *)tpalloc("STRING", NULL, 0);
        if (send == NULL) {
            fprintf(stderr, "tpalloc fail errno = %s\n", tpstrerror(tperrno));
            tpreturn(TPFAIL, 0, (char *)NULL, 0, TPNOFLAGS);
        }

        account_id = rcvbuf->account_id;
        branch_id = rcvbuf->branch_id;
        strcpy(phone, rcvbuf->phone);
        strcpy(address, rcvbuf->address);
        strcpy(ssn, "1234567");

        /*  Declare && Open Cursor for Fetch */
        EXEC SQL INSERT INTO ACCOUNT (
            ACCOUNT_ID,
            BRANCH_ID,
            SSN,
            PHONE,
            ADDRESS )
        VALUES (:account_id, :branch_id, :ssn, :phone, :address);

        if (sqlca.sqlcode != 0 && sqlca.sqlcode != 1403 )
        {
            printf("insert failed sqlcode = %d\n", sqlca.sqlcode);
            tpreturn(TPFAIL, -1, (char *)NULL, 0, TPNOFLAGS);
        }
        strcpy(send, OKMSG);
        tpreturn(TPSUCCESS, 1, (char *)send, strlen(send), TPNOFLAGS);
}

*DOMAIN
res         SHMKEY=88000, MINCLH=1, MAXCLH=5, TPORTNO=8880, BLOCKTIME=60

*NODE
tmax1       TMAXDIR="/user/ tmax ",
            APPDIR="/user/ tmax /appbin",
            PATHDIR = "/user/ tmax /path",
            TLOGDIR = "/user/ tmax /log/tlog",
            ULOGDIR="/user/ tmax /log/ulog",
            SLOGDIR="/user/ tmax /log/slog"

tmax2       TMAXDIR="/user/ tmax ",
            APPDIR="/user/ tmax /appbin",
            PATHDIR = "/user/ tmax /path",
            TLOGDIR = "/user/ tmax /log/tlog",
            ULOGDIR="/user/ tmax /log/ulog",
            SLOGDIR="/user/ tmax /log/slog"

*SVRGROUP
svg1        NODENAME = tmax1, DBNAME = ORACLE,
            OPENINFO = "ORACLE_XA+Acc=P/bmt/bmt+SesTm=60",
            TMSNAME = svg1_tms

svg2        NODENAME = tmax2, DBNAME = ORACLE,
            OPENINFO = "ORACLE_XA+Acc=P/bmt/bmt+SesTm=60",
            TMSNAME = svg2_tms

*SERVER
update      SVGNAME=svg1
insert      SVGNAME=svg2

*SERVICE
UPDATE      SVRNAME=update
INSERT      SVRNAME=insert

[tmax1]
TMAX_HOST_ADDR=192.168.1.39
TMAX_HOST_PORT=8880
SDLFILE=/user/tmax/sample/sdl/tmax.sdl
TMAX_CONNECT_TIMEOUT=5

struct input {
        int     account_id;
        int     branch_id;
        char    phone[15];
        char    address[61];
};

*DOMAIN
res         SHMKEY=88000, MINCLH=1, MAXCLH=5, TPORTNO=8880, BLOCKTIME=60

*NODE
tmax        TMAXDIR="/user/ tmax ",
            APPDIR="/user/ tmax /appbin",
            PATHDIR = "/user/ tmax /path",
            TLOGDIR = "/user/ tmax /log/tlog",
            ULOGDIR="/user/ tmax /log/ulog",
            SLOGDIR="/user/ tmax /log/slog"

*SVRGROUP
svg1        NODENAME = tmax, DBNAME = ORACLE,
            OPENINFO = "ORACLE_XA+Acc=P/bmt/bmt+SesTm=60",
            TMSNAME = svg1_tms

*SERVER
update      SVGNAME=svg1

*SERVICE
UPDATE      SVRNAME=update

[tmax]
TMAX_HOST_ADDR=192.168.1.39
TMAX_HOST_PORT=8880
SDLFILE=/user/tmax/sample/sdl/tmax.sdl
TMAX_CONNECT_TIMEOUT=5

#include <stdio.h>
#include <usrinc/atmi.h>
#include "../sdl/demo.s"

#define TEMP_PHONE "6283-2114"
#define TEMP_ADDRESS "Korea"

int main(int argc, char *argv[])
{
        struct input *sndbuf;
        char    *rcvbuf;
        int acnt_id, n, cd, timeout;
        long    len;

        if (argc != 2) {
            fprintf(stderr, "Usage:%s account_id \n", argv[0]);
            exit(1);
        }

        acnt_id = atoi(argv[1]);
        timeout = 5;

        n = tmaxreadenv("tmax.env", "tmax");
        if (n < 0) {
            fprintf(stderr, "tmaxreadenv fail! tperrno = %d\n", tperrno);
            exit(1);
        }

        n = tpstart((TPSTART_T *)NULL);
        if (n < 0) {
            fprintf(stderr, "tpstart fail! tperrno = %s\n", tperrno);
            exit(1);
        }

        sndbuf = (struct input *)tpalloc("STRUCT", "input", sizeof(struct input));
        if (sndbuf == NULL) {
            fprintf(stderr, "tpalloc fail: sndbuf tperrno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        rcvbuf = (char *)tpalloc("STRING", NULL, 0);
        if (rcvbuf == NULL) {
            fprintf(stderr, "tpalloc fail: rcvbuf tperrno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        sndbuf->account_id = acnt_id;
        sndbuf->branch_id = acnt_id;
        strcpy(sndbuf->phone, TEMP_PHONE);
        strcpy(sndbuf->address, TEMP_ADDRESS);
        tx_set_transaction_timeout(timeout);
        n = tx_begin();
        if (n < 0)
            fprintf(stderr, "tx begin fail! tperrno = %d\n", tperrno);

        cd = tpacall("UPDATE", (char *)sndbuf, sizeof(struct input), TPNOFLAGS);
        if (cd < 0) {
            fprintf(stderr, "tpacall fail! tperrno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        n = tpgetrply(&cd, (char **)&rcvbuf, (long *)&len, TPNOFLAGS);
        if (n < 0) {
            fprintf(stderr, "tpgetrply fail! tperrno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        n = tx_commit();
        if (n < 0) {
            fprintf(stderr, "tx commit fail! tx error = %d \n", n);
            tx_rollback();
            tpend();
            exit(1);
        }
        printf("rtn msg = %s\n", rcvbuf);
        tpfree((char *)sndbuf);
        tpfree((char *)rcvbuf);
        tpend();
}

#include <stdio.h>
#include <ctype.h>
#include <usrinc/atmi.h>
#include "../sdl/demo.s"

#define OKMSG "YOU COMPLETE THE TRANSACTION"

EXEC SQL include sqlca.h;

EXEC SQL BEGIN DECLARE SECTION;
        int     account_id;
        int     branch_id;
        char    ssn[15];
        char    phone[15];
        char    address[61];
EXEC SQL END DECLARE SECTION;

UPDATE(TPSVCINFO *msg)
{
        struct input *rcvbuf;
        int     ret, cd;
        long    acnt_id, rcvlen;
        char    *send;

        rcvbuf = (struct input *)(msg->data);
        send = (char *)tpalloc("STRING", NULL, 0);
        if (send == NULL) {
            fprintf(stderr, "tpalloc fail errno = %s\n", strerror(tperrno));
            tpreturn(TPFAIL, 0, (char *)NULL, 0, TPNOFLAGS);
        }
        account_id = rcvbuf->account_id;
        branch_id = rcvbuf->branch_id;
        strcpy(phone, rcvbuf->phone);
        strcpy(address, rcvbuf->address);
        strcpy(ssn, "1234567");

        EXEC SQL UPDATE ACCOUNT
        SET BRANCH_ID = :branch_id,
        PHONE = :phone,
        ADDRESS = :address,
        SSN = :ssn
        WHERE ACCOUNT_ID = :account_id;

        if (sqlca.sqlcode != 0 && sqlca.sqlcode != 1403 ) {
            fprintf(stderr, "update failed sqlcode = %d\n", sqlca.sqlcode);
            tpreturn(TPFAIL, -1, (char *)NULL, 0, TPNOFLAGS);
        }
        strcpy(send, OKMSG);
        tpreturn(TPSUCCESS, 1, (char *)send, strlen(send), TPNOFLAGS);
}

struct input {
        int     account_id;
        int     branch_id;
        char    phone[15];
        char    address[61];
};

*DOMAIN
res   SHMKEY=88000, MINCLH=1, MAXCLH=5, TPORTNO=8880, BLOCKTIME=60


*NODE
tmax        TMAXDIR="/user/ tmax ",
            APPDIR="/user/ tmax /appbin",
            PATHDIR = "/user/ tmax /path",
            TLOGDIR = "/user/ tmax /log/tlog",
            ULOGDIR="/user/ tmax /log/ulog",
            SLOGDIR="/user/ tmax /log/slog"

*SVRGROUP
svg1        NODENAME = tmax, DBNAME = ORACLE,
            OPENINFO = "ORACLE_XA+Acc=P/bmt/bmt+SesTm=60",
            TMSNAME = svg1_tms

*SERVER
update      SVGNAME=svg1, CONV=YES

*SERVICE
UPDATE      SVRNAME= update

[tmax]
TMAX_HOST_ADDR=192.168.1.39
TMAX_HOST_PORT=8880
SDLFILE=/user/tmax/sample/sdl/tmax.sdl
TMAX_CONNECT_TIMEOUT=5

#include <stdio.h>
#include <usrinc/atmi.h>
#include "../sdl/demo.s"

#define TEMP_PHONE "6283-2115"
#define TEMP_ADDRESS "Korea"

void main(int argc, char *argv[])
{
        struct input *sndbuf;
        char    *rcvbuf;
        int acntid, timeout;
        long revent, rcvlen;
        int cd, n;

        if (argc != 2) {
            fprintf(stderr, "Usage:%s acntid\n", argv[0]);
            exit(1);
        }

        acntid = atoi(argv[1]);
        timeout = 5;
        n = tmaxreadenv("tmax.env", "tmax");
        if (n < 0) {
            fprintf(stderr, "tmaxreadenv fail tperrno = %d\n", tperrno);
            exit(1);
        }

        n = tpstart((TPSTART_T *)NULL);
        if (n < 0) {
            fprintf(stderr, "tpstart fail tperrno = %s\n", tperrno);
            exit(1);
        }
        printf("tpstart ok!\n");
        sndbuf = (struct input *)tpalloc("STRUCT", "input", sizeof(struct input));
        if (sndbuf == NULL) {
            fprintf(stderr, "tpalloc fail: sndbuf tperrno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        rcvbuf = (char *)tpalloc("CARRAY", NULL, 0);
        if (rcvbuf == NULL) {
            fprintf(stderr, "tpalloc fail: rcvbuf tperrno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        sndbuf->account_id = acntid;
        sndbuf->branch_id = acntid;
        strcpy(sndbuf->phone, TEMP_PHONE);
        strcpy(sndbuf->address, TEMP_ADDRESS);

        tx_set_transaction_timeout(timeout);
        n = tx_begin();
        if (n < 0)
            fprintf(stderr, "tx begin fail tx error = %d\n", n);
        printf("tx begin ok!\n");

        cd = tpconnect("UPDATE", (char *)sndbuf, 0, TPSENDONLY);
        if (cd < 0) {
            fprintf(stderr, "tpconnect fail tperrno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        while (1) {
            n = tpsend(cd, (char *)sndbuf, sizeof(struct input), TPRECVONLY,
                       &revent);
            if (n < 0) {
                fprintf(stderr, "tpsend fail revent = 0x%08x\n", revent);
             tx_rollback();
                tpend();
                exit(1);
            }
            printf("tpsend ok\n");

            n = tprecv(cd, (char **)&rcvbuf, (long *)&rcvlen, TPNOTIME, &revent);
            if (n < 0 && revent != TPEV_SENDONLY) {
                fprintf(stderr, "tprecv fail revent = 0x%08x\n", revent);
                tx_rollback();
                tpend();
                exit(1);
            }
            printf("tprecv ok\n");
            sndbuf->account_id++;

            if (revent != TPEV_SENDONLY)
            break;
        }
        n = tprecv(cd, (char **)&rcvbuf, (long *)&rcvlen, TPNOTIME, &revent);
        if (n < 0 && revent != TPEV_SVCSUCC) {
            fprintf(stderr, "tprecv fail revent = 0x%08x\n", revent);
            tx_rollback();
            tpend();
            exit(1);
        }
        printf("rcvbuf = [%s]\n", rcvbuf);

        n = tx_commit();
        if (n < 0) {
            fprintf(stderr, "tx commit fail tx error = %d\n", n);
            tx_rollback();
            tpend();
            exit(1);
        }
        printf("tx commit ok!\n");
        printf("rtn msg = %s\n", rcvbuf);
        tpfree((char *)sndbuf);
        tpfree((char *)rcvbuf);
        tpend();
}

#include <stdio.h>
#include <ctype.h>
#include <usrinc/atmi.h>
#include "../sdl/demo.s"

void _db_work();

#define OKMSG "YOU COMPLETE THE TRANSACTION"

EXEC SQL include sqlca.h;
EXEC SQL BEGIN DECLARE SECTION;
        int     account_id;
        int     branch_id;
        char    ssn[15];
        char    phone[15];
        char    address[61];
EXEC SQL END DECLARE SECTION;

struct input *rcvbuf;

UPDATE(TPSVCINFO *msg)
{
        int     ret, count;
        long    acnt_id;
        long    revent, rcvlen, flag;
        char    *send;

        rcvbuf = (struct input *)tpalloc("STRUCT", "input", 0);
        send = (char *)tpalloc("CARRAY", NULL, 0);

        count = 1;
        flag = 0;

        while (1) {
            ret = tprecv(msg->cd, (char **)&rcvbuf, &rcvlen, TPNOTIME, &revent);
            if (ret < 0 && revent != TPEV_SENDONLY) {
                fprintf(stderr, "tprecv fail revent = 0x%08x\n", revent);
                tpreturn(TPFAIL, -1, (char *)rcvbuf, 0, TPNOFLAGS);
            }
            printf("tprecv ok!\n");

            if (count == 10) {
                flag &= ~TPRECVONLY;
                flag |= TPNOTIME;
            }
            else
                flag |= TPRECVONLY;

            ret = tpsend(msg->cd, (char *)send, strlen(send), flag, &revent);
            if (ret < 0) {
                fprintf(stderr, "tpsend fail revent = 0x%08x\n", revent);
                tpreturn(TPFAIL, -1, (char *)NULL, 0, TPNOFLAGS);
            }
            printf("tpsend ok!\n");
            _db_work();

            /* break after 10 iterations */
            if (count == 10)
                break;

            count++;
        }

        strcpy(send, OKMSG);
        printf("tpreturn ok!\n");
        tpreturn(TPSUCCESS, 1, (char *)send, strlen(send), TPNOFLAGS);
}

void _db_work() {
        account_id = rcvbuf->account_id;
        branch_id = rcvbuf->branch_id;
        strcpy(phone, rcvbuf->phone);
        strcpy(address, rcvbuf->address);
        strcpy(ssn, "1234567");

        EXEC SQL UPDATE ACCOUNT
        SET BRANCH_ID = :branch_id,
            PHONE = :phone,
            ADDRESS = :address,
            SSN = :ssn
            WHERE ACCOUNT_ID = :account_id;

        if (sqlca.sqlcode != 0 && sqlca.sqlcode != 1403) {
            fprintf(stderr, "update failed sqlcode = %d\n", sqlca.sqlcode);
            tpreturn(TPFAIL, -1, (char *)NULL, 0, 0);
        }
}

*DOMAIN
res          SHMKEY=78850,     MAXUSER=200, MINCLH=1, MAXCLH=5,
             TPORTNO=8850,     BLOCKTIME=60, TXTIME=50, RACPORT=3355

*NODE
tmaxh4         TMAXDIR="/data1/starbj81/tmax",
               APPDIR="/data1/starbj81/tmax/appbin",
               PATHDIR ="/data1/starbj81/tmax/path",
               TLOGDIR ="/data1/starbj81/tmax/log/tlog",
               ULOGDIR="/data1/starbj81/tmax/log/ulog",
               SLOGDIR="/data1/starbj81/tmax/log/slog"

*SVRGROUP
tsvg          NODENAME = "tmaxh4", SVGTYPE=TIP
svg1          NODENAME = "tmaxh4"

*SERVER
TIP            SVGNAME=tsvg, SVRTYPE=SYS_SVR, MIN=1, MAX=1
svr            SVGNAME=svg1, MIN=1

*SERVICE
TOUPPER        SVRNAME=svr

*DOMAIN
tmax          SHMKEY=98850,
              TPORTNO=8850,
              BLOCKTIME=60,
              RACPORT=3355,
              MAXUSER=10

*NODE
Tmaxh4         TMAXDIR="/data1/starbj81/tmax",
               APPDIR="/data1/starbj81/tmax/appbin",
               PATHDIR = "/data1/starbj81/tmax/path",
               TLOGDIR = "/data1/starbj81/tmax/log/tlog",
               ULOGDIR="/data1/starbj81/tmax/log/ulog",
               SLOGDIR="/data1/starbj81/tmax/log/slog"

tmaxh2         TMAXDIR="/data1/starbj81/tmax",
               APPDIR="/data1/starbj81/tmax/appbin",
               PATHDIR = "/data1/starbj81/tmax/path",
               TLOGDIR = "/data1/starbj81/tmax/log/tlog",
               ULOGDIR="/data1/starbj81/tmax/log/ulog",
               SLOGDIR="/data1/starbj81/tmax/log/slog"

*SVRGROUP
tsvg          NODENAME = "tmaxh4", SVGTYPE=TIP
svg1          NODENAME = "tmaxh4", COUSIN = "svg2"
svg2          NODENAME = "tmaxh2"


*SERVER
TIP          SVGNAME=tsvg, SVRTYPE=SYS_SVR, MIN=1, MAX=1
svr          SVGNAME=svg1, MIN=1, MAX=5

*SERVICE
TOUPPER       SVRNAME=svr, ROUTING = "rout1"

*ROUTING
rout1          FIELD="STRING", RANGES = "'bbbbbbb'-'ccccccc' : svg1, * :
               svg2

#
#       common field
#
# name          number  type    flags   comments
*base 16000001
TIP_OPERATION   0       string
TIP_SEGMENT     1       string
TIP_SECTION     2       string
TIP_NODE        3       string
TIP_OCCURS      4       int
TIP_FLAGS       5       int
TIP_CURSOR      6       string
TIP_SESTM       7       int
TIP_ERROR       8       int
TIP_STATE       9       int
TIP_MORE        10      int
TIP_BADFIELD    11      string
TIP_CMD         12      string
TIP_CLID        13      int
TIP_MSG         14      string

#
#       DOMAIN section fields
#
# name                  number  type    flags   comments
*base 16000100
TIP_NAME                0       string
TIP_SHMKEY              1       int
TIP_MINCLH              2       int
TIP_MAXCLH              3       int
TIP_MAXUSER             4       int
TIP_TPORTNO             5       int
TIP_RACPORT             6       int
TIP_MAXSACALL           7       int
TIP_MAXCACALL           8       int
TIP_MAXCONV_NODE        9       int
TIP_MAXCONV_SERVER      10      int
TIP_CMTRET              11      int
TIP_BLOCKTIME           12      int
TIP_TXTIME              13      int
TIP_IDLETIME            14      int
TIP_CLICHKINT           15      int
TIP_NLIVEINQ            16      int
TIP_SECURITY            17      string
TIP_OWNER               18      string
TIP_CPC                 19      int
#TIP_LOGINSVC           20      string
#TIP_LOGOUTSVC          21      string
TIP_NCLHCHKTIME         22      int
TIP_DOMAINID            23      int
TIP_IPCPERM             24      int
TIP_MAXNODE             25      int
TIP_MAXSVG              26      int
TIP_MAXSVR              27      int
TIP_MAXSVC              28      int
TIP_MAXSPR              29      int
TIP_MAXTMS              30      int
TIP_MAXCPC              31      int
TIP_MAXROUT             32      int
TIP_MAXROUTSVG          33      int
TIP_MAXRQ               34      int
TIP_MAXGW               35      int
TIP_MAXCOUSIN           36      int
TIP_MAXCOUSINSVG        37      int
TIP_MAXBACKUP           38      int
TIP_MAXBACKUPSVG        39      int
TIP_MAXTOTALSVG         40      int
TIP_MAXPROD             41      int
TIP_MAXFUNC             42      int
TIP_TXPENDINGTIME       43      int
TIP_NO                  44      int
TIP_TIPSVC              45      string
TIP_NODECOUNT           46      int
TIP_SVGCOUNT            47      int
TIP_SVRCOUNT            48      int
TIP_SVCCOUNT            49      int
TIP_COUSIN_COUNT                50      int
TIP_BACKUP_COUNT                51      int
TIP_ROUT_COUNT          52      int
TIP_STYPE               53      string
TIP_VERSION             54      string
TIP_EXPDATE             55      string
TIP_DOMAINCOUNT         56      int
TIP_RSVG_GCOUNT         57      int
TIP_RSVG_COUNT          58      int
TIP_CSVG_GCOUNT         59      int
TIP_CSVG_COUNT          60      int
TIP_BSVG_GCOUNT         61      int
TIP_BSVG_COUNT          62      int
TIP_PROD_COUNT          63      int
TIP_FUNC_COUNT          64      int
TIP_SHMSIZE             65      int
TIP_CRYPT               66      string
TIP_DOMAIN_TMMLOGLVL    67      string
TIP_DOMAIN_CLHLOGLVL    68      string
TIP_DOMAIN_TMSLOGLVL    69      string
TIP_DOMAIN_LOGLVL       70      string
TIP_DOMAIN_MAXTHREAD    71      int

#
#       NODE section fields
#
# name          number  type    flags   comments
*base 16000200
#TIP_NAME       0       string
TIP_DOMAINNAME  1       string
#TIP_SHMKEY     2       int
#TIP_MINCLH     3       int
#TIP_MAXCLH     4       int
TIP_CLHQTIMEOUT 5       int
#TIP_IDLETIME   6       int
#TIP_CLICHKINT  7       int
#TIP_TPORTNO    8       int
#TIP_TPORTNO2   9       int
#TIP_TPORTNO3   10      int
#TIP_TPORTNO4   11      int
#TIP_TPORTNO5   12      int
#TIP_RACPORT    13      int
#TIP_TMAXPORT   14      string
TIP_CMPRPORT    15      string
TIP_CMPRSIZE    16      int
#TIP_MAXUSER    17      int
TIP_TMAXDIR     18      string
TIP_TMAXHOME    19      string
TIP_APPDIR      20      string
TIP_PATHDIR     21      string
TIP_TLOGDIR     22      string
TIP_SLOGDIR     23      string
TIP_ULOGDIR     24      string
TIP_ENVFILE     25      string
#TIP_LOGINSVC   26      string
#TIP_LOGOUTSVC  27      string
TIP_IP          28      string
#TIP_PEER       29      string
TIP_TMMOPT      30      string
TIP_CLHOPT      31      string
#TIP_IPCPERM    32      int
#TIP_MAXSVG     33      int
#TIP_MAXSVR     34      int
#TIP_MAXSPR     35      int
#TIP_MAXTMS     36      int
#TIP_MAXCPC     37      int
TIP_MAXGWSVR    38      int
TIP_MAXRQSVR    39      int
TIP_MAXGWCPC    40      int
TIP_MAXRQCPC    41      int
TIP_CPORTNO     42      int
TIP_REALSVR     43      string
TIP_RSCPC       44      int
TIP_AUTOBACKUP  45      int
TIP_HOSTNAME    46      string
TIP_NODETYPE    47      int
TIP_CPU         48      int
#TIP_MAXRSTART  49      int
#TIP_GPERIOD    50      int
#TIP_RESTART    51      int
TIP_CURCLH      49      int
TIP_LIVECTIME   50      string
TIP_NODE_TMMLOGLVL      51      string
TIP_NODE_CLHLOGLVL      52      string
TIP_NODE_TMSLOGLVL      53      string
TIP_NODE_LOGLVL         54      string
TIP_NODE_MAXTHREAD      55      int
TIP_EXTPORT             56      int
TIP_EXTCLHPORT          57      int
TIP_MSGSIZEWARN 58      int
TIP_MSGSIZEMAX  59      int


#
#       SVRGROUP section fields
#
# name          number  type    flags   comments
*base 16000300
#TIP_NAME       0       string
#TIP_NODENAME   1       string
TIP_SVGTYPE     2       string
#TIP_PRODNAME   3       string
TIP_COUSIN      4       string
TIP_BACKUP      5       string
TIP_LOAD        6       int
#TIP_APPDIR     7       string
#TIP_ULOGDIR    8       string
TIP_DBNAME      9       string
TIP_OPENINFO    10      string
TIP_CLOSEINFO   11      string
TIP_MINTMS      12      int
#TIP_MAXTMS     13      int
TIP_TMSNAME     14      string
#TIP_SECURITY   15      string
#TIP_OWNER      16      string
#TIP_ENVFILE    17      string
#TIP_CPC                18      int
TIP_XAOPTION            19      string
TIP_SVG_TMSTYPE         20      string
TIP_SVG_TMSOPT          21      string
TIP_SVG_TMSTHREADS      22      int
TIP_SVG_TMSLOGLVL       23      string
TIP_SVG_LOGLVL          24      string
TIP_NODENAME            25      string

#
#       SERVER section fields
#
# name          number  type    flags   comments
*base 16000350
#TIP_NAME       0       string
TIP_SVGNAME     1       string
#TIP_NODENAME   2       string
TIP_CLOPT       3       string
TIP_SEQ         4       int
TIP_MIN         5       int
TIP_MAX         6       int
#TIP_ULOGDIR    7       string
TIP_CONV        8       int
TIP_MAXQCOUNT   9       int
TIP_ASQCOUNT    10      int
TIP_MAXRSTART   11      int
TIP_GPERIOD     12      int
TIP_RESTART     13      int
TIP_SVRTYPE     14      string
#TIP_CPC                15      int
TIP_SCHEDULE    16      int
#TIP_MINTHR     17      int
#TIP_MAXTHR     18      int
TIP_TARGET      19      string
TIP_DEPEND      20      string
TIP_CASCADE     21      int
TIP_PROCNAME    22      string
TIP_LIFESPAN    23      string
TIP_DDRI        24      string
TIP_CURSVR      25      int
TIP_SVGNO       26      int
TIP_SVR_LOGLVL  27      string


#
#       SERVICE section fields
#
# name          number  type    flags   comments
*base 16000400
#TIP_NAME       0       string
TIP_SVRNAME     1       string
TIP_PRI         2       int
TIP_SVCTIME     3       int
TIP_ROUTING     4       string
TIP_EXPORT      5       int
TIP_AUTOTRAN    6       int

#
#       ROUTING section fields
#
# name          number  type    flags   comments
*base 16000425
#TIP_NAME       0       string
TIP_FLDTYPE     1       string
TIP_RANGES      2       string
TIP_SUBTYPE     3       string
TIP_ELEMENT     4       string
TIP_BUFTYPE     5       string
TIP_OFFSET      6       int
TIP_FLDLEN      7       int
#TIP_FLDOFFSET  8       int

#
#       RQ section fields
#
# name          number  type    flags   comments
*base 16000450
#TIP_NAME       0       string
#TIP_SVGNAME    1       string
TIP_PRESVC      2       string
TIP_QSIZE       3       int
TIP_FILEPATH    4       string
TIP_BOOT        5       string
TIP_FSYNC       6       int
TIP_BUFFERING   7       int
#TIP_ENQSVC     8       int
#TIP_FAILINTERVAL 9     int
#TIP_FAILRETRY  10      int
#TIP_FAILSVC    11      string
#TIP_AFTERSVC   12      string

#
#       GATEWAY section fields
#
# name                  number  type    flags   comments
*base 16000500
#TIP_NAME               0       string
TIP_GWTYPE              1       string
TIP_PORTNO              2       int
#TIP_CPC                        3       int
TIP_RGWADDR             4       string
TIP_RGWPORTNO           5       int
#TIP_BACKUP             6       string
#TIP_NODENAME           7       string
TIP_KEY                 8       string
TIP_BACKUP_RGWADDR      9       string
TIP_BACKUP_RGWPORTNO    10      int
TIP_TIMEOUT             11      int
TIP_DIRECTION           12      string
TIP_MAXINRGW            13      int
TIP_GWOWNER             15      string
TIP_RGWOWNER            16      string
TIP_RGWPASSWD           17      string
TIP_PTIMEOUT            18      int
TIP_PTIMEINT            19      int

#
#       FUNCTION section fields
#
# name          number  type    flags   comments
*base 16000550
#TIP_NAME       0       string
#TIP_SVRNAME    1       string
TIP_FQSTART     2       int
TIP_FQEND       3       int
TIP_ENTRY       4       string


#
#       STATISTICS segment fields
#
# name          number  type    flags   comments
*base 16000600
#TIP_NAME       0       string
TIP_STATUS      1       string
TIP_STIME       2       string
TIP_TTIME       3       int
TIP_SVC_STIME   4       int
TIP_COUNT       5       int
#TIP_NO         6       int
TIP_NUM_FREE    7       int
TIP_NUM_REPLY   8       int
TIP_NUM_FAIL    9       int
TIP_NUM_REQ     10      int
TIP_ENQ_REQS    11      int
TIP_DEQ_REQS    12      int
TIP_ENQ_REPLYS  13      int
TIP_DEQ_REPLYS  14      int
TIP_CLHNO       15      int
TIP_SVR_NAME    16      string
TIP_SVC_NAME    17      string
TIP_AVERAGE     18      float
TIP_QCOUNT      19      int
TIP_CQCOUNT     20      int
TIP_QAVERAGE    21      float
TIP_MINTIME     22      float
TIP_MAXTIME     23      float
TIP_FAIL_COUNT  24      int
TIP_ERROR_COUNT 25      int
TIP_PID         26      int
TIP_TOTAL_COUNT 27      int
TIP_TOTAL_SVCFAIL_COUNT 28      int
TIP_TOTAL_ERROR_COUNT   29      int
TIP_TOTAL_AVG   30      float
TIP_TOTAL_RUNNING_COUNT 31      int
TIP_TMS_NAME    32      string
TIP_SVG_NAME    33      string
TIP_SPRI        34      int
TIP_TI_THRI     35      int
TIP_TI_AVG      36      float
TIP_TI_XID      37      string
TIP_TI_XA_STATUS        38      string
TIP_GW_NAME     39      string
TIP_GW_NO       40      int
TIP_GW_HOSTN    41      string
TIP_GW_CTYPE    42      string
TIP_GW_CTYPE2   43      string
TIP_GW_IPADDR   44      string
TIP_GW_PORT     45      int
TIP_GW_STATUS   46      string

#
#       ADMIN segment fields
#
# name          number  type    flags   comments
*base 16000650
TIP_IPADDR      0       string
TIP_USRNAME     1       string
TIP_MODULE      2       int
TIP_LOGLVL      3       string
TIP_SPEC        4       string

#
#       boot time
#
# name          number  type    flags   comments
TIP_BOOTTIME_SEC        5       int
TIP_BOOTTIME_MSEC       6       int

#
#       EXTRA flag fields
#
# name          number  type    flags   comments
*base 16000700
TIP_EXTRA_OPTION        0       int
TIP_SVRI        1       int
TIP_QPCOUNT     2       int
TIP_EMCOUNT     3       int
TIP_SVR_STATUS  4       string

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <ctype.h>
#include <usrinc/atmi.h>
#include <usrinc/fbuf.h>
#include <usrinc/tip.h>

#define SEC_DOMAIN          1
#define SEC_NODE            2
#define SEC_SVGROUP         3
#define SEC_SERVER          4
#define SEC_SERVICE         5
#define SEC_ROUTING         6
#define SEC_RQ              7
#define SEC_GATEWAY         8

main(int argc, char *argv[])
{
        FBUF    *sndbuf, *rcvbuf;
        TPSTART_T *tpinfo;
        int   i, n, sect;
        long  rcvlen;
        char  nodename[NAMELEN];
        int   pid, count = 0;

        if (argc != 3) {
            printf("Usage: %s section nodename\n", argv[0]);
            printf("section:\n");
            printf("\t1: domain\n");
            printf("\t2: node\n");
            printf("\t3: svrgroup\n");
            printf("\t4: server\n");
            printf("\t5: service\n");
            printf("\t6: routing\n");
            printf("\t7: rq\n");
            printf("\t8: gateway\n");
            exit(1);
        }

        if (!isdigit(argv[3][0])) {
            printf("fork count must be a digit\n");
            exit(1);
        }
        count = atoi(argv[3]);

        sect = atoi(argv[1]);
        if (sect < SEC_DOMAIN || sect > SEC_GATEWAY) {
            printf("out of section [%d - %d]\n", SEC_DOMAIN, SEC_GATEWAY);
            exit(1);
        }

        strncpy(nodename, argv[2], sizeof(nodename) - 1);

        n = tmaxreadenv("tmax.env", "TMAX");
        if (n < 0) {
           fprintf(stderr, "can't read env\n");
           exit(1);
        }

        tpinfo = (TPSTART_T *)tpalloc("TPSTART", NULL, 0);
        if (tpinfo == NULL) {
            printf("tpalloc fail tperrno = %d\n", tperrno);
            exit(1);
        }
        strcpy(tpinfo->usrname, ".tpadmin");
        if (tpstart((TPSTART_T *)tpinfo) == -1){
            printf("tpstart fail [%s]\n", tpstrerror(tperrno));
            exit(1);
        }

        if ((sndbuf = (FBUF *)tpalloc("FIELD", NULL, 0)) == NULL) {
            printf("tpalloc failed! errno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        if ((rcvbuf = (FBUF *)tpalloc("FIELD", NULL, 0)) == NULL) {
            printf("tpalloc failed! errno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        n = fbput(sndbuf, TIP_OPERATION, "GET", 0);
        n = fbput(sndbuf, TIP_SEGMENT, "CONFIGURATION", 0);
        switch (sect) {
            case SEC_DOMAIN:
                n = fbput(sndbuf, TIP_SECTION, "DOMAIN", 0);
                break;
            case SEC_NODE:
                n = fbput(sndbuf, TIP_SECTION, "NODE", 0);
                break;
            case SEC_SVGROUP:
                n = fbput(sndbuf, TIP_SECTION, "SVGROUP", 0);
                break;
            case SEC_SERVER:
                n = fbput(sndbuf, TIP_SECTION, "SERVER", 0);
                break;
            case SEC_SERVICE:
                n = fbput(sndbuf, TIP_SECTION, "SERVICE", 0);
                break;
            case SEC_ROUTING:
                n = fbput(sndbuf, TIP_SECTION, "ROUTING", 0);
                break;
            case SEC_RQ:
                n = fbput(sndbuf, TIP_SECTION, "RQ", 0);
                break;
            case SEC_GATEWAY:
                n = fbput(sndbuf, TIP_SECTION, "GATEWAY", 0);
                break;
        }

        n = fbput(sndbuf, TIP_NODENAME, nodename, 0);

        n = tpcall("TIPSVC", (char *)sndbuf, 0, (char **)&rcvbuf,  &rcvlen,
                    TPNOFLAGS);
        if (n < 0) {
                printf("tpcall fail [%s]\n", tpstrerror(tperrno));
                fbprint(rcvbuf);
                tpfree((char *)sndbuf);
                tpfree((char *)rcvbuf);
                tpend();
                exit(1);
        }

#if 1
        fbprint(rcvbuf);
#endif

        tpfree((char *)sndbuf);
        tpfree((char *)rcvbuf);
        tpend();
}

$ client 1 tmaxh4
fkey = 217326601, fname = TIP_ERROR, type = int, value = 0
...
fkey = 485762214, fname = TIP_CRYPT, type = string, value = NO
    fkey = 485762215, fname = TIP_DOMAIN_TMMLOGLVL, type = string, value = DEBUG1
    fkey = 485762216, fname = TIP_DOMAIN_CLHLOGLVL, type = string, value = DEBUG2
    fkey = 485762217, fname = TIP_DOMAIN_TMSLOGLVL, type = string, value = DEBUG3
    fkey = 485762218, fname = TIP_DOMAIN_LOGLVL, type = string, value = DEBUG4
    fkey = 217326763, fname = TIP_DOMAIN_MAXTHREAD, type = int, value = 128

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <usrinc/atmi.h>
#include <usrinc/fbuf.h>
#include <usrinc/tip.h>

#define SEC_NODE        1
#define SEC_TPROC       2
#define SEC_SPR         3
#define SEC_SERVICE     4
#define SEC_RQ          5
#define SEC_TMS         6
#define SEC_TMMS        7
#define SEC_CLHS        8
#define SEC_SERVER        9

#define NODE_NAME_SIZE 32

main(int argc, char *argv[])
{
        FBUF    *sndbuf, *rcvbuf;
        TPSTART_T *tpinfo;
        int   i, n, sect;
        long  rcvlen;
        char  nodename[NODE_NAME_SIZE];
        int stat;

        if (argc != 3) {
            printf("Usage: %s section node\n", argv[0]);
            printf("section:\n");
            printf("\t1: node\n");
            printf("\t2: tproc\n");
            printf("\t3: spr\n");
            printf("\t4: service\n");
            printf("\t5: rq\n");
            printf("\t6: tms\n");
            printf("\t7: tmms\n");
            printf("\t8: clhs\n");
            printf("\t9: server\n");
            exit(1);
        }

        sect = atoi(argv[1]);
        if (sect < SEC_NODE || sect > SEC_CLHS) {
            printf("out of section [%d - %d]\n",SEC_NODE, SEC_TMMS);
            exit(1);
        }

        memset(nodename, 0x00, NODE_NAME_SIZE);
        strncpy(nodename, argv[2], NODE_NAME_SIZE - 1);

        n = tmaxreadenv("tmax.env", "TMAX");
        if (n < 0) {
           fprintf(stderr, "can't read env\n");
           exit(1);
        }

        tpinfo = (TPSTART_T *)tpalloc("TPSTART", NULL, 0);
        if (tpinfo == NULL) {
            printf("tpalloc fail tperrno = %d\n", tperrno);
            exit(1);
        }
        strcpy(tpinfo->dompwd, "xamt123");

        if (tpstart((TPSTART_T *)tpinfo) == -1){
            printf("tpstart fail tperrno = %d\n", tperrno);
            exit(1);
        }

        if ((sndbuf = (FBUF *)tpalloc("FIELD", NULL, 0)) == NULL) {
            printf("tpalloc failed! errno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        if ((rcvbuf = (FBUF *)tpalloc("FIELD", NULL, 0)) == NULL) {
            printf("tpalloc failed! errno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        n = fbput(sndbuf, TIP_OPERATION, "GET", 0);
        n = fbput(sndbuf, TIP_SEGMENT, "STATISTICS", 0);
        switch (sect) {
            case SEC_NODE:
                n = fbput(sndbuf, TIP_SECTION, "NODE", 0);
                break;
            case SEC_TPROC:
                n = fbput(sndbuf, TIP_SECTION, "TPROC", 0);
                break;
            case SEC_SPR:
                n = fbput(sndbuf, TIP_SECTION, "SPR", 0);
                break;
            case SEC_SERVICE:
                n = fbput(sndbuf, TIP_SECTION, "SERVICE", 0);
                break;
            case SEC_RQ:
                n = fbput(sndbuf, TIP_SECTION, "RQ", 0);
                break;
            case SEC_TMS:
                stat = 1;
                n = fbput(sndbuf, TIP_SECTION, "TMS", 0);
                n = fbput(sndbuf, TIP_EXTRA_OPTION, (char *)&stat, 0);
                break;
            case SEC_TMMS:
                n = fbput(sndbuf, TIP_SECTION, "TMMS", 0);
                break;
            case SEC_CLHS:
                n = fbput(sndbuf, TIP_SECTION, "CLHS", 0);
                break;
            case SEC_SERVER:
                n = fbput(sndbuf, TIP_SECTION, "SERVER", 0);
                break;
        }
        n = fbput(sndbuf, TIP_NODENAME, nodename, 0);

        n = tpcall("TIPSVC", (char *)sndbuf, 0, (char **)&rcvbuf,
                    &rcvlen, TPNOFLAGS);
        if (n < 0) {
            printf("tpcall fail [%s]\n", tpstrerror(tperrno));
            fbprint(rcvbuf);
            tpfree((char *)sndbuf);
            tpfree((char *)rcvbuf);
            tpend();
            exit(1);
        }

        fbprint(rcvbuf);

        tpfree((char *)sndbuf);
        tpfree((char *)rcvbuf);
        tpend();
}

$  client 3000 1 2
fkey = 217326601, fname = TIP_ERROR, type = int, value = 0
fkey = 485762680, fname = TIP_TMS_NAME, type = string, value = tms_ora2
fkey = 485762681, fname = TIP_SVG_NAME, type = string, value = xa1
fkey = 217327226, fname = TIP_SPRI, type = int, value = 0
fkey = 485762649, fname = TIP_STATUS, type = string, value = RUN
fkey = 217327197, fname = TIP_COUNT, type = int, value = 0
fkey = 351544938, fname = TIP_AVERAGE, type = float, value = 0.000000
fkey = 217327212, fname = TIP_CQCOUNT, type = int, value = 0
fkey = 217327227, fname = TIP_TI_THRI, type = int, value = 1
fkey = 351544956, fname = TIP_TI_AVG, type = float, value = 0.000000
fkey = 485762685, fname = TIP_TI_XID, type = string, value = 00000013664
fkey = 485762686, fname = TIP_TI_XA_STATUS, type = string, value = COMMIT

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <ctype.h>
#include <usrinc/atmi.h>
#include <usrinc/fbuf.h>
#include <usrinc/tmaxapi.h>
#include <usrinc/tip.h>

#define NODE_NAME_SIZE  32

main(int argc, char *argv[])
{
        FBUF    *sndbuf, *rcvbuf;
        TPSTART_T *tpinfo;
        int   i, n, type, clid, count, flags;
        long  rcvlen;
        char  svrname[TMAX_NAME_SIZE];
        char  svgname[TMAX_NAME_SIZE];
        char  nodename[NODE_NAME_SIZE];
        int   pid, forkcnt;

        if (argc != 6) {
            printf("Usage: %s type svrname count nodename forkcnt\n", argv[0]);
            printf("type 1: BOOT, 2: DOWN, 3: DISCON\n");
            exit(1);
        }

        type = atoi(argv[1]);
        if ((type != 1) && (type != 2) && (type != 3)) {
            printf("couldn't support such a type %d\n", type);
            exit(1);
        }

        if (strlen(argv[2]) >= TMAX_NAME_SIZE) {
            printf("too large name [%s]\n", argv[1]);
            exit(1);
        }
        strcpy(svrname, argv[2]);
        count = atoi(argv[3]);
        flags = 0;

        strncpy(nodename, argv[4], NODE_NAME_SIZE - 1);
        forkcnt = atoi(argv[5]);

        n = tmaxreadenv("tmax.env", "TMAX");
        if (n < 0) {
           fprintf(stderr, "can't read env\n");
           exit(1);
        }

        tpinfo = (TPSTART_T *)tpalloc("TPSTART", NULL, 0);
        if (tpinfo == NULL) {
            printf("tpalloc fail tperrno = %d\n", tperrno);
            exit(1);
        }
        strcpy(tpinfo->usrname, ".tpadmin");

        for (i = 1; i < forkcnt; i++) {
            if ((pid = fork()) < 0)
                exit(1);
            else if (pid == 0)
                break;
        }

        if (tpstart((TPSTART_T *)tpinfo) == -1){
            printf("tpstart fail tperrno = %d\n", tperrno);
            exit(1);
        }

        if ((sndbuf = (FBUF *)tpalloc("FIELD", NULL, 0)) == NULL) {
            printf("tpalloc failed! errno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        if ((rcvbuf = (FBUF *)tpalloc("FIELD", NULL, 0)) == NULL) {
            printf("tpalloc failed! errno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        n = fbput(sndbuf, TIP_OPERATION, "GET", 0);
        n = fbput(sndbuf, TIP_SEGMENT, "ADMINISTRATION", 0);
        if (type == 1)
            n = fbput(sndbuf, TIP_CMD, "BOOT", 0);
        else if (type == 2)
            n = fbput(sndbuf, TIP_CMD, "DOWN", 0);
        else
            n = fbput(sndbuf, TIP_CMD, "DISCON", 0);

        if (type == 3) {
            clid = count;       /* at type 3 */
            flags |= TIP_SFLAG;
            n = fbput(sndbuf, TIP_CLID, (char *)&clid, 0);
            n = fbput(sndbuf, TIP_FLAGS, (char *)&flags, 0);
        } else {
            flags |= TIP_SFLAG;
            n = fbput(sndbuf, TIP_SVRNAME, svrname, 0);
            n = fbput(sndbuf, TIP_COUNT, (char *)&count, 0);
            n = fbput(sndbuf, TIP_FLAGS, (char *)&flags, 0);
        }

        n = fbput(sndbuf, TIP_NODENAME, nodename, 0);

        n = tpcall("TIPSVC", (char *)sndbuf, 0, (char **)&rcvbuf,
                    &rcvlen, TPNOFLAGS);
        if (n < 0) {
            printf("tpcall failed! errno = %d[%s]\n", tperrno, tpstrerror(tperrno));
            fbprint(rcvbuf);
            tpfree((char *)sndbuf);
            tpfree((char *)rcvbuf);
            tpend();
            exit(1);
        }

        fbprint(rcvbuf);

        tpfree((char *)sndbuf);
        tpfree((char *)rcvbuf);
        tpend();

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <ctype.h>
#include <usrinc/atmi.h>
#include <usrinc/fbuf.h>
#include <usrinc/tmaxapi.h>
#include <usrinc/tip.h>
#include "../fdl/tip_fdl.h"

#define NFLAG 32
#define GFLAG 8
#define VFLAG 1024

int case_chlog(int, char *[], FBUF *);

#define NODE_NAME_SIZE  32

main(int argc, char *argv[])
{
      FBUF    *sndbuf, *rcvbuf;
      TPSTART_T *tpinfo;
      int   i, ret, n, type, clid, count, flags = 0;
      long  rcvlen;
      char  svrname[TMAX_NAME_SIZE];
      char  svgname[TMAX_NAME_SIZE];
      char  nodename[NODE_NAME_SIZE];
      int   pid, forkcnt;

      if (argc < 6) {
          printf("Usage: %s svgname svrname nodename  [chlogmodule] [flags]
                                                      [loglvl]\n", argv[0]);
          printf("chlogmodule 1: TIP_TMM, 2: TIP_CLH, 4: TIP_TMS, 8: TIP_SVR\n");
          printf("flags 1: NFLAGS, 2: GFLAGS, 3: VFLAGS\n");
          printf("loglvl : 1: compact, 2: basic, 3: detail, 4: debug1, 5: debug2,
                           6: debug3, 7: debug4\n");
          exit(1);
      }

      n = tmaxreadenv("tmax.env", "TMAX");
      if (n < 0) {
          fprintf(stderr, "can't read env\n");
          exit(1);
       }

       tpinfo = (TPSTART_T *)tpalloc("TPSTART", NULL, 0);
       if (tpinfo == NULL) {
           printf("tpalloc fail tperrno = %d\n", tperrno);
           exit(1);
        }
        strcpy(tpinfo->usrname, ".tpadmin");
        strcpy(svgname, argv[1]);
        strcpy(svrname, argv[2]);
        strncpy(nodename, argv[3], NODE_NAME_SIZE - 1);

        if (tpstart((TPSTART_T *)tpinfo) == -1){
            printf("tpstart fail tperrno = %d\n", tperrno);
            exit(1);
        }

        if ((sndbuf = (FBUF *)tpalloc("FIELD", NULL, 0)) == NULL) {
            printf("tpalloc failed! errno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        if ((rcvbuf = (FBUF *)tpalloc("FIELD", NULL, 0)) == NULL) {
            printf("tpalloc failed! errno = %d\n", tperrno);
            tpend();
            exit(1);
        }

        ret = case_chlog(argc, argv, sndbuf);
        n = fbput(sndbuf, TIP_OPERATION, "GET", 0);
        n = fbput(sndbuf, TIP_SEGMENT, "ADMINISTRATION", 0);
        n = fbput(sndbuf, TIP_CMD, "CHLOG", 0);
        n = fbput(sndbuf, TIP_NODENAME, nodename, 0);
        n = fbput(sndbuf, TIP_SVGNAME, svgname , 0);
        n = fbput(sndbuf, TIP_SVRNAME, svrname, 0);

        n=tpcall("TIPSVC", (char *)sndbuf, 0, (char **)&rcvbuf, &rcvlen, TPNOFLAGS);
        if (n < 0) {
             printf("tpcall failed! errno = %d[%s]\n", tperrno, tpstrerror(tperrno));
             fbprint(rcvbuf);
             tpfree((char *)sndbuf);
             tpfree((char *)rcvbuf);
             tpend();
             exit(1);
        }

        fbprint(rcvbuf);
        tpfree((char *)sndbuf);
        tpfree((char *)rcvbuf);
        tpend();
}

int case_chlog(int argc2, char *argv2[], FBUF *sndbuf)
{
        int  chlogmdl, loglvl, flags, n=0;
        char  cloglvl[TMAX_NAME_SIZE];
        const int true = 1, false = 0;

        chlogmdl = atoi(argv2[4]);
        if( (chlogmdl != 1) && (chlogmdl != 2) && (chlogmdl != 4) &&
            (chlogmdl != 8) {
                printf("couldn't support such a chlogmdl\n");
                exit(1);
        }

        flags = atoi(argv2[5]);
        if( (flags != NFLAG) && (flags != GFLAG) && (flags != VFLAG) ) {
                printf("couldn't support such a flags\n");
                exit(1);
        }

        loglvl = atoi(argv2[6]);
        if( (loglvl < 1) || (loglvl > 7) ) {
                printf("couldn't support such a loglvl\n");
                exit(1);
        }

        switch (loglvl)
        {
                case 1 :
                        strcpy(cloglvl, "compact");
                        break;
                case 2 :
                        strcpy(cloglvl, "basic");
                        break;
                case 3 :
                        strcpy(cloglvl, "detail");
                        break;
                case 4 :
                        strcpy(cloglvl, "debug1");
                        break;
                case 5 :
                        strcpy(cloglvl, "debug2");
                        break;
                case 6 :
                        strcpy(cloglvl, "debug3");
                        break;
                case 7 :
                        strcpy(cloglvl, "debug4");
                        break;
        }
        n = fbput(sndbuf, TIP_MODULE, (char *)&chlogmdl, 0);
        n = fbput(sndbuf, TIP_FLAGS, (char *)&flags , 0);
        n = fbput(sndbuf, TIP_LOGLVL, cloglvl , 0);
        return 1;
}

$ client  xa1 svr23_stat_ins $HOSTNAME 8 1024 7
fkey = 217326601, fname = TIP_ERROR, type = int, value = 0
>>> tmadmin (cfg -v)

         loglvl = DEBUG4
